• Model NO.：GM-SB-114NCB
• Type：Pipe and Tube Bending Machine
• Transport Package：Iron Frame
• Trademark：GMACC
• Origin：China
• Production Capacity：5000PCS,Year

Basic Info.

Model NO. GM-SB-114NCB Type Pipe and Tube Bending Machine Transport Package Iron Frame Trademark GMACC Origin China Production Capacity 5000PCS/Year

Product Description

GM-SB-114NCB automatically bend in the same machine suitable for continuous automatic workpiece complete different direction, a number of different angles of three-dimensional workpieces, using the touch-screen machine operators and industrial computer control procedures, is an efficient, economical automatic pipe bender.

1. Construction Machine
Body by welding, mechanical parts assembly, import hydraulic system, electronic control of imports of fabric to complete.

2. Major performances
Using industrial touch screen, in English mode menu is simple, with high precision, fast, multifunctional and high degree of automation. Each action of machine is controlled by PLC programme control system.

3. The technical parameters
Name Unit GM-114NCB
Max. Bending Capacity mm 114*10
Bending Radius Region mm 80-450
Bending Angle Region ° 0- 190
Max. Through Effective Distance mm 2800
Bending Precision ° ± 0.10
Bending Speed r /min 0-3
Turn Pipe Precision ° ± 0.10
Turn Pipe Speed ° /sec 160
Feeding Precision mm ± 0.10
Feeding Speed mm/sec 800
Motor Power of Oil Pump System KW 11
Max. Pressure MPA 16
General Length*Width*Height mm 6500*1350*1200
General Weight T 5.8

Configuration of Hydraulic and Electronic Control System

Name	Manufacturer
Hydraulic Motor	Suzhou Jialifan
Hydraulic Pump	Wuxi Tuoli
Hydraulic Valve	Japan Yuken(Imported)
Oil way Board	Taiwan Shanghong (Imported)
Cylinder	Shanghai Qifan
Oil tube	Taiwan TATUNG(Imported)
Touch screen	Taiwan Weinview
PLC	Japan Mitsubishi(Imported)
Angle controller	Japan Nemicon
Switch power	Taiwan Mean Well(Imported)
Contactor	Taiwan SHIHLIN(Imported)
Other Electric Parts	German SCHNEIDER, Omron, Taiwan SHILIN(Imported)
