Chinese Best Electric and CNC Hydraulic Pipe Rolling Bender, Wheelbarrow 3D Full Automatic Profile or Furniture Pipe Tube Bending Machine (GM-SB-38CNC-A-1S)

Zhangjiagang King-Macc Machinery Manufacturing Co., Ltd.
  • Waterproof Rating：IPX-8
  • Warranty：1-year
  • Condition：New
  • Certification：ISO 9001:2000, CE
  • Automation：Semi-Automatic
  • Suitable for：Copper, Aluminum, Carbon Steel, Stainless Steel

Base Info

  • Model NO.：GM-SB-114NCB
  • Type：Hydraulic Bending Machine
  • Transport Package：Iron Frame
  • Specification：5300x1350x1200mm
  • Trademark：GMACC
  • Origin：China
  • HS Code：8462219000
  • Production Capacity：5000PCS,Year

Description

Basic Info.

Model NO. GM-SB-114NCB Type Hydraulic Bending Machine Transport Package Iron Frame Specification 5300x1350x1200mm Trademark GMACC Origin China HS Code 8462219000 Production Capacity 5000PCS/Year

Product Description

Technical Parameter and Configuration for Automatic Pipe Bending Machine GM-SB-114NCB
  • Machine CharacteristicFull hydraulic drove, PLC controlled with touch screen or text pipe bending machine, equipped with devices of pipe clamping, guide mould, mandrel, crease-resistant, assist pushing, pipe bending and so on. Under hydraulic operation, this professional, high speed and economic European pipe bending machine can bend various dimension both normal and abnormal shape metal pipes and bending angles are controlled by high precision imported encoder which ensures high precision of this machine.

  • Main Technical Parameter
NameUnit Parameter
Max. Bending Capacitymm¢114*12
Bending Radius Rangemm40-500
Max. Bending Angle° 190°
Though Effective Distancemm3500
Bending Speed°/sec20
Bending Precision°±0.10
System Motor PowerKW15
Oil Pump Delivery VolumeL36
Max. PressureMpa16
L*W*H (Packaging Dimension)mm4800*1350*1300
Machine WeightT5.5

  • Configuration of Hydraulic and Electronic Control System
NameManufacturer
Hydraulic MotorSuzhou Runmali
Hydraulic PumpWuxi Tuoli
Hydraulic ValveJapan Yuken(Imported)
Oil way BoardTaiwan Shanghong (Imported)
CylinderShanghai Qifan
Oil tubeSuzhou Kejia
Touch screenTaiwan Weinview(Imported)
PLCJapan Mitsubishi(Imported)
Angle controllerJapan Nemicon(Imported)
Switch powerWenzhou Changjiang
ContactorGerman SCHNEIDER(Imported)
Other Electric PartsGerman SCHNEIDER,Omron, Taiwan SHILIN(Imported)
