• Model NO.：GM-350NC-350CNC
• Type：Pipe and Tube Bending Machine
• Transport Package：Iron Frame
• Specification：Gm-350-420
• Trademark：GMACC
• Origin：China
• Production Capacity：5000PCS,Year

Basic Info.

Model NO. GM-350NC-350CNC Type Pipe and Tube Bending Machine Transport Package Iron Frame Specification Gm-350-420 Trademark GMACC Origin China Production Capacity 5000PCS/Year

Product Description

Copper/Aluminum Cutting Machine:
1. Hydraulic driven
2. High speed
3. Low noisy, smooth cutting
4. High accuracy and efficienc

The Main Parameters and Configuration of GM-CA-350/420CNC Copper/Aluminium Cutting Machine

GM-CA-350/420CNC full-auto copper/aluminum cutting machine is a kind of automatic feeding Materials, automatic cutting machine, cutting various cross section shapes to aluminium materials, Copper materials, and in particular the copper-aluminium material is ideal cutting equipment

1. Construction Machine
Bed used welding pieces, imports of hydraulic systems and electric control three of fabric to complete. The electric parts and hydraulic are imported.
2. Design Principle
In the process of cutting, the other work piece clamping, feed sawing, cut back knife, tongs loosened By the electrical, hydraulic control order.
3. Major Performance
The machine is operated light, noise and no dust pollution, cutting good internal and external incisions, No thorns, production efficiency, and the advantages of scarfed various angles

4. Configuration
A) Hydraulic pump: Made in Taiwan
Hydraulic valve of the Taiwan original imports
Cylinder: Shanghai
B) Electronic parts
Motor: Made in Taiwan
Button Switch: Made in Taiwan
Photoelectric switches and Electrical: Made in Taiwan
PLC: Made in Taiwan

Name	Unit		GM-AD-350, 420CNC Servo (Full Auto)
Cutting Capacity(90° )	mm	bar	75
	mm	pipe	110
	mm	square	100× 100
	mm	rectangle	150× 80
The motor power	KW		2.2
The rotating speed	giri/min		3000
The largest opening of pincers	mm		160
The diameter of saw blade	mm		400
Machine weight	kg		900
