• Model NO.：DB-38
• Machine Type：Hydraulic Tube Bending Machine
• Certificates：Ce, ISO9001
• Color：Blue or Customized
• Special Function：Two or Three Tubes Bend Together
• Modle：dB-38
• Brand：Sanco
• Technology：Taiwan
• Max Capacity：Od38*2mm
• 3D Bending：Available
• Head Rotary：Available
• Transport Package：Wooden Case
• Specification：1200kgs
• Trademark：Sanco
• Origin：China
• HS Code：846221
• Production Capacity：3000 Sets,Year

Basic Info.

Model NO. DB-38 Machine Type Hydraulic Tube Bending Machine Certificates Ce, ISO9001 Color Blue or Customized Special Function Two or Three Tubes Bend Together Modle dB-38 Brand Sanco Technology Taiwan Max Capacity Od38*2mm 3D Bending Available Head Rotary Available Transport Package Wooden Case Specification 1200kgs Trademark Sanco Origin China HS Code 846221 Production Capacity 3000 Sets/Year

Product Description

Patient Walker Bending Hydraulic Machine

 Bend two bends one time
 Available for 3D bending
Hole punching function as option



Sample:


Technical Data

Name	Specification
Max.Capacity(O.D×WT)	Mild steel¢40×2.0 mm
Capacity of bending	Φ40mm X 1  pipe Φ25mm X 2  pipes Φ16mm X 3  pipes Φ13mm X 4  pipes
Bending	Hydraulic
Rotating Machine Head	3600 rotating for 3D bending
Max. bending angle	185°
Distance between two bends	Standard: 140 - 2000 mm Option: According to customer
Bending speed	90°/sec
Bending precision	±0.05°
Max. Pressure	12MP (Adjustable)
Woking noise	≤60db
Screen language	English / other
Program storage	Maximum 20 sets
