• Model NO.：GT-WB-60-10A
• Type：Cnc Bending Machine
• Axis：10
• Weight：3500kg
• Application：Wire Bending
• After-Sales Service Provided：Engineers Available to Service Machinery Overseas
• Wire Size：2.0-6.0mm
• Transport Package：Standard Fumugated Wooden Case
• Trademark：XINSHENG
• Origin：Guangdong, China (Mainland)
• HS Code：8462219000
• Production Capacity：2 Set Per Month

Basic Info.

Model NO. GT-WB-60-10A Type Cnc Bending Machine Axis 10 Weight 3500kg Application Wire Bending After-Sales Service Provided Engineers Available to Service Machinery Overseas Wire Size 2.0-6.0mm Transport Package Standard Fumugated Wooden Case Trademark XINSHENG Origin Guangdong, China (Mainland) HS Code 8462219000 Production Capacity 2 Set Per Month

Product Description

10 Axis 3D CNC Heavy-duty Metal Wire Bending Forming Machine

Product Description
CNC wire bending machine CNC 3D wire bending machine  is to produce kinds of wire forms expertly with high precision and fast speed. Adopts Japanese Sanyo Denki servo motor and screen display with Taiwan controller.

Advantages & Features:

1.3-4 pairs feeding roller , feeding motor fixed on the bottom base, so as to decrease the feeding box weight, that wire rotating is more fast and light , turning angle is more precise and stable.
2.Twisting head is designed in copper tube transport, more stable and stronger than bearing transfer
Technical parameters

Techanical Data:

Wire size(mm)	2.0-6.0
axis	10
feeding roller number	3 pairs
wire turning angle	unlimited
platform lifting height	20-100mm
twisting head lift height	50-170mm
distance between cutting is and bending head	/
distance between bending head and machine body	/
out twisting lifting height	20-55mm
left to right moving range	left :80mm,right:40mm
Feeding front and back moving range	front:300mm  back:300mm
machine size(mm)	3500x1200x1500
machine weight(kg)	3500

10 Aixs 3D CNC Heavy-duty Metal Wire Bending Forming Machine show
