• Model NO.：B5063
• Slotting length：200mm
• Max.Weight of working piece：400kgs
• table diameter：500mm
• color：As Customer Request
• Transport Package：Plywood Case
• Specification：CE SGS ISO9001
• Trademark：HOTON
• Origin：Shandong China
• HS Code：846120200
• Production Capacity：5 PCS,Month

Basic Info.

Model NO. B5063 Slotting length 200mm Max.Weight of working piece 400kgs table diameter 500mm color As Customer Request Transport Package Plywood Case Specification CE SGS ISO9001 Trademark HOTON Origin Shandong China HS Code 846120200 Production Capacity 5 PCS/Month

Product Description

SLOTTING MACHINE FEATURES:
1.The working table of the machine tool is provided with three different directions of feed (longitudinal, horizontal and rotary), therefore work object go through once clamping,Several surfaces in the machine tool machining
2.Hydraulic transmission mechanism with sliding pillow reciprocating motion and hydraulic feed device for working table.
3.The sliding pillow has the same speed in every stroke, and the movement speed of the ram and the working table can be adjusted continuously.
4.Hydraulic control table have ram commutation oil for oil reversing mechanism,In addition to hydraulic and manual feed outer,Even there single motor drive vertical, horizontal and rotary fast moving.
5.Use hydraulic feed the slotting machine,Is when the work is over  turning back instantaneous feed,Therefore be better than mechanical slotting machine used drum wheel feed.
SPECIFICATION:

SPECIFICATION	B5020D	B5032D	B5040	B5050A
Max slotting length	200mm	320mm	400mm	500mm
Max dimensions of workpiece (LxH)	485x200mm	600x320mm	700x320mm	-
Max weight of workpiece	400kg	500kg	500kg	2000kg
Table diameter	500mm	630mm	710mm	1000mm
Max longitudinal travel of table	500mm	630mm	560/700mm	1000mm
Max cross travel of table	500mm	560mm	480/560mm	660mm
Range of table power feeds (mm)	0.052-0.738	0.052-0.738	0.052-0.783	3,6,9,12,18,36
Main motor power	3kw	4kw	5.5kw	7.5kw
Overall dimensions (LxWxH)	1836x1305x1995	2180x1496x2245	2450x1525x2535	3480x2085x3307
