• Model NO.：ESR-2020x3.5 ESR-1300x6.5
• Type：Manual Bending Machine
• Bed Width：1300mm
• Max. thickness：2.5mm
• motor：1.5kw
• Weight：560kgs
• packing size：200X72X120cm
• Transport Package：Plywood Case
• Specification：CE SGS ISO9001
• Trademark：HOTON
• Origin：Shandong, China
• HS Code：84622990
• Production Capacity：20 PCS,Month

Basic Info.

Model NO. ESR-2020x3.5 ESR-1300x6.5 Type Manual Bending Machine Bed Width 1300mm Max. thickness 2.5mm motor 1.5kw Weight 560kgs packing size 200X72X120cm Transport Package Plywood Case Specification CE SGS ISO9001 Trademark HOTON Origin Shandong, China HS Code 84622990 Production Capacity 20 PCS/Month

Product Description

SPECIFICATIONS OF ELECTRIC SLIP ROLLER MACHINE FROM HOTON MACHINERY
1.Metal Electric Slip Roll Machine supplied with conical bending feature
2. Fixed top roller, adjustable lower and rear rollers
3. The maximum processing capacity of the heavy electric rolling machine can reach 4.5 mm
4. The electric rolling machine not only reels but also can cone the materials
5. It can roll the round bar steels whose specifications are ¢6, ¢8, ¢10 and so on.
6. The electric rolling machine features a roller quenching that is more durable
7. The upper axis is fixed. The electric rolling machine runs through adjusting the lower and rea axes
8. The locking structure of upper roller can smooth the roller's operation
9. The 24V pedal switch is safe and easy to operate
10. The safety mechanism of electric rolling machine is in line with the CE standard

Model	Max.Thickness (mm)	Max. Width (mm)	Dia.of roll (mm)	Motor Power (kW)	Packing size (cm)	N.W./G.W.(kg)
ESR-1300x2.5	2.5	1300	90	1.5	200x72x120	540/600
ESR-1300x4.5	4.5	1300	120	2.2	200x76x127	750/830
ESR-1550x3.5	3.5	1550	120	2.2	222x76x127	790/890
ESR-2020x3.5	3.5	2020	127	40	270x87x130	1100/1300
ESR-1300x6.5	6.5	1300	150	3	282x87x134	1100/1190
ESR-2070x2.5	2.5	2070	120	2.2	282x87x130	1060/1200
ESR-2070x3.5	3.5	2070	127	3	282x87x130	1110/1250
