Vertical Slotting Machine (B5032D B5020D)
Tengzhou Hoton Machinery Co., Ltd.- Condition:New
- Certification:ISO 9001:2008, CE
- Automation:Automatic
- Suitable for:Metal
- Type:Cnc Bending Machine
- motor:3KW
Base Info
- Model NO.:B5032D
- Slotting length:200mm
- Max.Weight of working piece:400kgs
- table diameter:500mm
- color:As Customer Request
- Transport Package:Plywood Case
- Specification:CE SGS ISO9001
- Trademark:HOTON
- Origin:Shandong China
- HS Code:846120200
- Production Capacity:5 PCS,Month
Description
Basic Info.
Model NO. B5032D Slotting length 200mm Max.Weight of working piece 400kgs table diameter 500mm color As Customer Request Transport Package Plywood Case Specification CE SGS ISO9001 Trademark HOTON Origin Shandong China HS Code 846120200 Production Capacity 5 PCS/MonthProduct Description
SLOTTING MACHINE FEATURES:
Features:This machine is used to process planes,model surfaces,key seating ect,is most suitable for the single-piece or small batch production
The main transmission is to change the crank gear's rotary motion into the reciprocating motion of the ram.
Worktable can be vertical, horizontal and rotary moving, maual or automatic and fast moving.The feed will stopped automatically when worktable is meet trouble or achieve limit.
The start and stop adopt electromagnetism clutch, realize centralized control.
Angle dividing device for table roatry dividing, do machining as required angle.
This machine is well designed as standard,universalization,serialization,automation.Good appearance and convenient maintenance.
Automatic lubrication,easy adjustment
The electric equipment is fixed in the bed at the back of lower bed. it is safe because of the concentrated push buttons in the upper bed.
SPECIFICATION:
SPECIFICATION | B5020D | B5032D | B5040 | B5050A |
Max slotting length | 200mm | 320mm | 400mm | 500mm |
Max dimensions of workpiece (LxH) | 485x200mm | 600x320mm | 700x320mm | - |
Max weight of workpiece | 400kg | 500kg | 500kg | 2000kg |
Table diameter | 500mm | 630mm | 710mm | 1000mm |
Max longitudinal travel of table | 500mm | 630mm | 560/700mm | 1000mm |
Max cross travel of table | 500mm | 560mm | 480/560mm | 660mm |
Range of table power feeds (mm) | 0.052-0.738 | 0.052-0.738 | 0.052-0.783 | 3,6,9,12,18,36 |
Main motor power | 3kw | 4kw | 5.5kw | 7.5kw |
Overall dimensions (LxWxH) | 1836x1305x1995 | 2180x1496x2245 | 2450x1525x2535 | 3480x2085x3307 |
