• Model NO.：WC67K-80T,2500 with E200 controller
• Slider Travel：100 Times,Min
• Max Open：320
• Power：7.5kw
• Weight of Machine：5000kg
• Diamension：2500X1400X2300
• Coloer：White Blue Red Black or Opertional
• Type for Fold-Bending Machine：Hydraulic Fold-Bend Machine
• Transport Package：Plastic Film Corvered
• Specification：CE
• Trademark：ZYMT
• Origin：China
• Production Capacity：1500 Sets,Year

Basic Info.

Model NO. WC67K-80T/2500 with E200 controller Slider Travel 100 Times/Min Max Open 320 Power 7.5kw Weight of Machine 5000kg Diamension 2500X1400X2300 Coloer White Blue Red Black or Opertional Type for Fold-Bending Machine Hydraulic Fold-Bend Machine Transport Package Plastic Film Corvered Specification CE Trademark ZYMT Origin China Production Capacity 1500 Sets/Year

Product Description

Bending Machine/Press Brake With Light Beam WC67K-80T/2500 with E200 NC controller

Advantage of E200:
1. Bright LCD display, 240*128; Multiple working steps programmed at one time and executed automatically, continuous positioning avaliable
2. Automatic retraction to avoid possible impacts between workpiece and backguage
3. One side positioning, screw gap is eliminated
4. Inch/mm selection; Position compensation; Power down position memorization
5. Automatic searching for reference points and power down position memorization are offered to customer as options



Descriptions:
1. The whole machine is in sheet plate welded structure, with internal stress eliminated by vibration aging technology, high strengh and good rigidity of machine;
2. Double hydraulic oil cylinder is applied for upper transmission, provided with mechnical limit stopper and synchronous torsion bar, typical of stable and reliable operation, as well as high precision;
3. Electrical control and manual fine-tuning mode are adopted for distance of rear stopper and stroke of gliding block, and fitted with digital display device, easy and quick in use;
4. Upper die is fitted with deflection compensation device.



Packing&Delivery:
With more than 10 years exporting experience, we are so skilled for loading containers and packing the machines in container for safety. Each machine use min. 6mm dimeter steel rope to fix the four angles with the container, to avoid the machinery equipment move in the container.

Our Services:

1.24 hours telephone line is available for any question.

2.Experienced service technician team is available.

3.Support in hard work solution.
