Factory Price Metal Pipe Tube Proessing Machine in China

Zhangjiagang Caos Precision Machinery Manufacturing Co., Ltd.
  • Condition：New
  • Certification：ISO 9001:2008, CE
  • Automation：Automatic
  • Suitable for：Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel
  • Model：Sb50CNC
  • Max Bending Radiu：250mm

Base Info

  • Model NO.：SB50cNC
  • Min Bending Radiu：25mm
  • Max Wear Core：2400mm
  • Max Bending Angle：185
  • Bend Pipe Fittings Can Be Set：16
  • The Data Input Mode：Y.B.C
  • Turing Servo Motor：400W
  • Feeding Servo Moter：1.5kw
  • Machine Size：3500*1550*1050
  • Transport Package：Wood
  • Specification：SB50cNC
  • Trademark：CAOS
  • Origin：China
  • HS Code：8401200000
  • Production Capacity：100set,Per Year

Description


Specification/Model1. SB50CNC
 RemarkMax bending capabilityΦ50mm×3mm
1. The Minimum bending diameter of CNC bending machine based on the pipe diameter
2.The Max bending diameter of CNC bending machine can accordingto the customers requirement
3.The Max length of mandrel of CNC bending machine can according to customers requirement
Max bending radiusR250mmMin bending radiusR20mmMax bending angle190°Max feeding length2600mmfeeding methoddirect feeding
clamping feedingWorking speedBending speedMax 85°/sRotary speedMax 200°/sFeeding speedMax 1000mm/sWorking accuracyBending accuracy±0.1°Rotary accuracy±0.1°Feeding accuracy±0.1mmInformation inputting method1. axisX . Y. Z
2.working valueY. B. CBending method1.Servo bending : 1kw(more than 3 axis
2. Hydraulic bendingPower of rotary servo motor750wPower of feeding servo motor1kwMax bending groups1. 12
2. 33Max storing components1. 330
2. 125Motor power7.5kwOil pressure12 MpaSize4900 x 1300 x 1300mmWeight2500kgVideo for our machine:
