12X3200 Hydraulic Shearing Machine with Nc Control System

Shanghai YingXin World Machinery Co., Ltd.
  • After-sales Service:Yes
  • Automation:Automatic
  • Certification:CE
  • Condition:New
  • Warranty:1 Year
  • 12X3200 Shearing Machine:Hydraulic Cutting Machine

Base Info

  • Model NO.:QC11Y-12x3200
  • Cutting Thickness:12mm
  • Cutting Length:3200mm
  • Control:Nc
  • Transport Package:in Container
  • Specification:ISO
  • Trademark:WORLD
  • Origin:China
  • HS Code:84295100
  • Production Capacity:5000 PCS,Year

Description

Basic Info.

Model NO. QC11Y-12x3200 Cutting Thickness 12mm Cutting Length 3200mm Control Nc Transport Package in Container Specification ISO Trademark WORLD Origin China HS Code 84295100 Production Capacity 5000 PCS/Year

Product Description

12x3200 hydraulic shearing machine with NC system

Features:


1)Entirely steel welded frame, treated to release stress by tempering.
2)Hydraulic drive, return of knife beam is smooth and prompt by nitrogen cylinder.
3)Adopts rolling guideway to raise shear precision.
4)The stroke of knife beam can be adjusted.
5)With counter.
6)Shearing angle can be adjusted.
7)With protection fence.


12X3200 Hydraulic Shearing Machine with Nc Control System
12X3200 Hydraulic Shearing Machine with Nc Control System
12X3200 Hydraulic Shearing Machine with Nc Control System
12X3200 Hydraulic Shearing Machine with Nc Control System
12X3200 Hydraulic Shearing Machine with Nc Control System
12X3200 Hydraulic Shearing Machine with Nc Control System



Specifications
ItemsunitQC11Y-6x2500QC11Y-6x3200QC11Y-6x4000
Max. cutting thicknessmm666
Max. cutting widthmm250032004000
Tensile strength of plate to be cutN/mm2450450450
Cutting angledeg0.5-1.50.5-1.50.5-1.5
Travel distance of back gaugemm20-55020-55020-600
Throat depthmm150150150
Stroke speedsspm16-2612-2210-20
Main motorkW7.57.57.5
Lengthmm300037004800
Widthmm150016501650
Heightmm200020502250
ItemsunitQC11Y-8x2500QC11Y-8x3200QC11Y-8x4000
Max. cutting thicknessmm888
Max. cutting widthmm250032004000
Tensile strength of plate to be cutN/mm2450450450
Cutting angledeg0.5-20.5-20.5-2
Travel distance of back gaugemm20-60020-60020-600
Throat depthmm150150150
Stroke speedsspm14-2512-2010-20
Main motorkW111111
Lengthmm304038604800
Widthmm170017001800
Heightmm215023502480
ItemsunitQC11Y-10x2500QC11Y-10x3200QC11Y-10x4000
Max. cutting thicknessmm101010
Max. cutting widthmm250032004000
Tensile strength of plate to be cutN/mm2450450450
Cutting angledeg0.5-1.50.5-1.50.5-1.5
Travel distance of back gaugemm20-60020-60020-600
Throat depthmm150150150
Stroke speedsspm12-2010-2010-18
Main motorkW111515
Lengthmm304038604800
Widthmm170017001800
Heightmm215023502480
