• Model NO.：ZYB-100T,3200
• Seal Ring：Fietz,Nok, Germany,Japan
• Pump：Rexroth, Bosch Germany
• Footswitch：Karcon, South Korea
• Backgauge Travel：500mm
• Transport Package：Plastic Cover
• Specification：CE, ISO, SGS
• Trademark：ZYMT
• Origin：Anhui, China
• HS Code：8462219000
• Production Capacity：3000sets,Year

TypeNominal Force
(KN)Worktable Length
(mm)Vertical Distance
(mm)Throat Depth
(mm)Stroke
(mm)Max Open
(mm)Power
(kw)X-travel
(mm)X-speed63T/2500630250019003501703805.5



500






200mm/s100T/32001000320027004002004207.5125T/320012503200270040020042011160T/320016003200270040020042011200T/320020003200270040020042015250T/320025003200270040020042015300T/320030003200270040020042022400T/400040004000350040032042030500T/600050006000490050032060037


800600T/600060006000490050032060045800T/600080006000490060040060055800T/8000800080005900600400600551000T/6000100001000049006004006002×371000T/8000100001000069006004006002×371000T/1000100001000080006004006002×37
CNC Controller

DA52S
Quick, one page programming. Hotkey navigation. 7″VGA colour TFT
Up to 4 axes(Y1,Y2, and 2 auxiliary axes).Crowning control Tool/material/product library. USB, peripheral interfacing .
Advanced Y-axis control algorithms for closed loop as well as open loop valves.

DA56S
2D graphical programming, 10,4″LCD TFT colour display.
Bend sequence determination, developed length calculation.
Crowning control, USB peripheral interfacing.
Advanced Y-axis control algorithms for closed-loop as well as open-loop valves.

DA66T
2D graphical touch screen programming mode.
3D visualization in simulation and production.
17″high resolution colour TFI, full windows application suite.
DELEM Modusys compatibility(module scalability and adaptivity)
USB, peripheral interfacing.
User specific application support within the controllers multitasking environment.
Sensor bending & correction interface.

DA69T
3D and 2D graphical touch screen programming mode.
3D visualization in simulation and production.
17″high resolution colour TFI, full windows application suite.
DELEM Modusys compatibility(module scalability and adaptivity)
USB, peripheral interfacing.
User specific application support within the controllers multitasking environment.
Sensor bending & correction interface.

ESA S540
10.2″TFT VGA colour display with antiglare screen, ergonomic moulded plastic housing.
With a panel suitable for machine operational selector-switches and push-buttons;
Following arms, thickness detector, in-process angle measurement units, robotic interfacing, controlling for tandem press-brakes.
Interactive 3D graphic editor for work-piece and tools data entry.
Manual 2D graphic identification of the best bending sequence.
Programming of the axes position in tabular mode with automatic syntactical checks, automatic calculation of the R and Z position and of the bending and crowing tonnage.
Windows® like user interface and Multi-language.

ESA S530
Graphic monochrome 5.7″LCD display(320*240 pixels resolution)
Programming of the axes position in tabular mode with automatic syntactical checks, automatic calculation of the R and Z position and of the bending and crowing tonnage.
All programs, tools description, parameters can be stored on the internal memory or on USB memory stick. These files can be exchanged with other CNC and PC through USB memory stick.
Selectable and programmable axes and auxiliary functions.
Control 3 axes.

DNC880S
Keyboard: Large keys easy to use with working gloves 10.4″TFT colour LCD screen.
Language: 17 dialogue language.
Axes: 4 axes standard configuration, or up to 7 axes.
CPU: Via Eden 400MHz, RAM: 256MB (standard version)
Mass memory: Compact Flash (1GB), Port: USB, RS232, RJ45
Ethernet, VGA
Product and tool memory 300MB, Integrated OEM Panel.

Packaging & Shipping
(1)Before packing, the machine tool will be testing for 48 hours to ensure all the equipment is 100% qualitied.
(2)Before loading, stable package, professional and skilled loader reduce damage of product during transport.
(3)After loading, our professional documentary staff will follow the order till the product departs from port.

Our service
1. Shearing blades and accessories-Customized to your specifications.In our shearing blades, our focus is on first-class, practical, well-thought-out upper and lower tools. Our tools offer solutions to your application cases-even for complex technical ones.
2. Service package
Basic: we offer you rapid trouble shooting through telephone support and costs for on-site missions are reduced.
Special: Engineers available to service machinery overseas for the necessary maintenance.



1.24 hours telephone line is available for any question.

2.Experienced service technician team is available.

3.Support in hard work solution.
