• Model NO.：zyb-1600t*8000
• Type for Fold-Bending Machine：CNC Fold-Bend Machine
• Main Motor：Siemens
• Electrics：Schneider
• Hydraulic Valve：Rexroth
• Pump：Rexroth
• Toolings：Lianmeng
• Ball Screw：Hiwin
• Footswitch：Karcon
• Transport Package：Plastic Cover
• Specification：CE
• Trademark：ZYMT
• Origin：China
• HS Code：8462299000
• Production Capacity：3000sets,Year

Model
(ZYB-)1200t/
60001200t/
70001600t/
60001600t/
70001600t/
80001600t/
100002000t/
80002000t/
100002000t/
120002000t/
140003000t/
80003000t/
100003000t/
120003000t/
14000Nominal force(KN)1200012000160016001600160020002000200020003000300030003000Bending length(mm)600070006000700080001000080001000012000140008000100001200014000Vertical distance(mm)4900590049005900690080006200800090501100062008000905011000Throat depth(mm)600600600600600600600600600600600600600600Stroke (mm)400400400400400400400400400400400400400400Max. opening(mm)800800800800800800800800800800800800800800Main power(KN)2*372*372*552*552*552*552*552*552*552*552*552*552*552*55Axes3+1(Y1,Y2,X,V)CompensationMotorized compensationX-travel(mm)1000X-speed200mm/sOverall length(mm)650085006500720085001050085001050012500145008500105001250014500Overall width(mm)31003100330033003300330035003500350035003700370037003700Overall height(mm)58507150650070008000800080008300830083008600860086008600Approximate weight(ton)130160150170190210260290320350////
Main components of ZYB model:
(Standard)
1. Control System: DELEM DA52S
2. Servo motor and drive: Estun China
3. Hydraulic System: HOERBGER /
BOSCH Germany
4. Ball bearing lead screw:
Taiwan HIWIN
5. Straight-line guide:
Taiwan HIWIN
6. Connector: Germany EMB
7. Seal ring: Germany FIETZ or
Japanese VALQUA
8. Raster Ruler: Heidemhain Germany
9. Main electrical elements:
TE/OMROM/SIEMENS
10. Standard axes: Y 1 , Y 2 , X and V( V
for crowing table)


Optional:
1. DELEM DA56
2. DELEM DA66T
3. R/Z1/Z2-axis
4. Laser beam
5. Light beam

Packing&Delivery:

With more than 10 years exporting experience, we are so skilled for loading containers and packing the machines in container for safety. Each machine use min. 6mm dimeter steel rope to fix the four angles with the container, to avoid the machinery equipment move in the container.

Our Services:

1.24 hours telephone line is available for any question.

2.Experienced service technician team is available.

3.Support in hard work solution.

Certifications:
