• Model NO.：WC,E67Y,K
• Color：Grey
• Application：Machinery & Hardware
• Type for Fold-bending Machine：Hydraulic Fold-bend Machine
• Type for Pipe and Tube Bending Machine：Horizontal Hydraulic Pipe Bender
• Transport Package：Standard Export Package
• Specification：ISO
• Trademark：Yaoqiang
• Origin：Jiangsu, China
• Production Capacity：100 Pieces,Year

Basic Info.

Model NO. WC/E67Y/K Color Grey Application Machinery & Hardware Type for Fold-bending Machine Hydraulic Fold-bend Machine Type for Pipe and Tube Bending Machine Horizontal Hydraulic Pipe Bender Transport Package Standard Export Package Specification ISO Trademark Yaoqiang Origin Jiangsu, China Production Capacity 100 Pieces/Year

Product Description

Hydraulic Plate CNC Bending MachineMain features:

1. Totally steel welding structure. Internal stress eliminated via vibration aging, with good strength and stability.
2. Rate of flow from servo proportional valve, and data from electronic meter, together control the sliders Y1&Y2 synchronous movement.
3. Slide repetition accuracy is 0.01mm, the bending angle is 0.5 º
4. Slider low and fast speed switch position and up limit stop position are sensed by grating ruler, and which feedback to computer and then adjust.

Equipment quality promise:
1, the Company's manufacturing facilities are applicable to the relevant national standards and enterprise standards.
2, the company's products are manufactured to meet the technical requirements and parameters should be listed in the specification and to ensure safety and reliability.
3, the company may send engineers to the demand-side participation to help guidance of installation and commissioning of equipment until the machine is qualified and can be put into use. Also we can help the demand side with training equipment operators and maintenance personnel. (Note: The installation and commissioning of equipment abroad, we will take cost in accordance with the cost of a standard international practice)
4 Equipment has 1 year warranty, during the warranty period, the company can track service and maintenance.

Our services:
1. Oversea engineers:
We provide oriented after-sales service including the oversea engineers tranning available and also international dealer center for any emergency guidance. We have established worldwide network to guarantee our timely response for your any demand no matter where you are.
2. Learning trip:
We welcome engineers from your side to learn the technical design and normal maintenance here, this will help you easyly to understanding.
3. English Manual:
We have Mannual to show you along with the machine. So you can learn this from the existing document to deeper your knowledge and understanding.
4. Face to face to teacing:
Through internet video face to face for machine teaching, because of the high development in internet, the world has become smaller and you can easy contact us if any assistance needed.
5. Through all the ways, we will guarantee the service quality and ensure you will be well helped anything anywhere.

Type	Nominal Pressue	Working table length(mm)	Distance withine standing columns(mm)	Open height(mm)	Throat depth(mm)	Backgauge range(mm)	Motpr power(mm)
WC/E67Y/K-40T/2500	400	2500	2050	210	200	110	4
WC/E67Y/K-63T/2500	630	2500	2050	235	250	120	5.5
WC/E67Y/K-80T/2500	800	2500	2050	330	320	120	7.5
WC/E67Y/K-80T/3200	800	3200	2560	330	320	120	7.5
WC/E67Y/K-100T/2500	1000	2500	2050	330	320	120	7.5
WC/E67Y/K-100T/3200	1000	3200	2500	330	320	150	7.5
WC/E67Y/K-100T/4000	1000	4000	2960	400	320	120	7.5
WC/E67Y/K-125T/3200	1250	3200	2500	330	320	150	7.5
WC/E67Y/K-125T/4000	1250	2500	2960	330	320	120	7.5
WC/E67Y/K-160T/3200	1600	3200	2500	400	320	200	11
WC/E67Y/K-160T/4000	1600	400	2940	400	320	200	11
WC/E67Y/K-160T/6000	1600	600	4600	400	320	200	11
WC/E67Y/K-200T/3200	2000	3200	2500	435	300	200	15
WC/E67Y/K-200T/4000	2000	4000	3100	435	300	200	15
WC/E67Y/K-200T/6000	2000	6000	4800	435	320	200	15
WC/E67Y/K-250T/3200	2500	3200	2500	435	320	200	18.5
WC/E67Y/K-250T/4000	2500	4000	3100	435	320	200	18.5
WC/E67Y/K-250T/6000	2500	6000	4800	435	350	200	18.5
WC/E67Y/K-300T/3200	3000	3200	2600	435	350	200	22
WC/E67Y/K-300T/4000	3000	4000	3100	435	350	200	22
WC/E67Y/K-300T/6000	3000	6000	4800	435	350	200	22

Our company:
Jiangsu Yaoqiang Technical Group is a dealers holding type and high-tech enterprise. It mainly supply welding, cutting, milling, pipe producing production line as well as electrical automation equipment. The group consists of Jiangsu Silver Coast International Trading Development Co., Ltd (locate in Wuxi)& Dongtai Yaoqiang Mechinery Manufacture Co., Ltd. While Wuxi company, which is located in National technical industry park, i. e.The Wuxi Liandong U Valley, besides the Taihu lake with beautiful scenery and renowned humanities, is mainly focus on enterprise blue print, R&D, marketing,trading, management and finance. The Dongtai plant is devoted to technics, manufacture, process control, test and after-service, which locates at Dongtai Tangyang Xinhong Machinery industry park, in the wet land area off the seashore of Huanghai.
So we are manufacturer and trader. The Wuxi part is for trading and Dongtai part is for producing.

Here we make a promise to you all: we will offer you the products with the ideal price and good quality.
If you have any problems or you are interested in our products, Please contact me via Email or following ways:

Tel:0086-15261533318
