• Model NO.：GM-SB-50CNC-2A-1S
• Type：Pipe and Tube Bending Machine
• Transport Package：Iron Frame
• Trademark：GMACC
• Origin：China
• HS Code：846219000
• Production Capacity：5000PCS,Year

Basic Info.

Model NO. GM-SB-50CNC-2A-1S Type Pipe and Tube Bending Machine Transport Package Iron Frame Trademark GMACC Origin China HS Code 846219000 Production Capacity 5000PCS/Year

Product Description

GM-50CNC automatically bend in the same machine suitable for continuous automatic workpiece complete different direction, a number of different angles of three-dimensional workpieces, using the touch-screen machine operators and industrial computer control procedures, is an efficient, economical automatic pipe bender.

1 Construction Machine
The European plane bend light machine reliability, with Asian features similar mechanical products from manufacturers; Bed adopt a plate welding, casting steel form. The use of imported hydraulic system control; Electronic imports by servo motors, industrial computers and touch-screen operation panel.

2 Main performance
Using touch-screen operation panel and PLC control system, the Chinese mode menu is simple, accurate, fast, complete functions, a high degree of automation features, and have not lost power procedures and the characteristics of the workpiece parameters.

Name unit GM-50CNC
Max. Siphon Capacity mm 50*2.0
Max. Bending Radius Region mm 35-250
Max. Bending Angle Region ° 190
Max. Through Effective Distance mm 4100
Bending Precision ° ± 0.10
Feeding Precision mm ± 0.10
Feeding Speed mm/sec 900
Turn Pipe Precision ° ± 0.10
Turn Pipe Speed deg/sec 200
Motor Power of Oil Pump System KW 5.5
Oil Pump Displacement L 19
General Power KW 7.75
Max. Pressure Map 12
General Length*Width*Height mm 5500*800*1300
General Weight T 2.2


Name	Manufacturer
Hydraulic Motor	Suzhou Jialifan
Hydraulic Pump	Wuxi Tuoli
Hydraulic Valve	Japan Yuken(Imported)
Oil way Board	Taiwan Shanghong (Imported)
Cylinder	Shanghai Qifan
Oil tube	Taiwan TATUNG(Imported)
Touch screen	Taiwan Weinview
PLC	Japan Mitsubishi(Imported)
Angle controller	Japan Nemicon
Switch power	Taiwan Mean Well(Imported)
Contactor	Taiwan SHIHLIN(Imported)
Other Electric Parts	German SCHNEIDER, Omron, Taiwan SHILIN(Imported)
