Large CNC Hydraulic Press Brake (Large Series)
ACE Machine Tools Co., Ltd.- Warranty：1-year
- Condition：New
- Certification：ISO 9001:2000, CE, UL
- Suitable for：Carbon Steel, Stainless Steel
- Bending Length：4000-12000mm
- Transport Package：PVC
Base Info
- Model NO.：Large Series
- Specification：CE
- Trademark：Acemachinetools
- Origin：China
- HS Code：84622990
- Production Capacity：100sets,Month
Description
Model
500×4000500×5000 500×6000 600×6000 600×7000 600×8000 800×6000 800×7000 Capacity kN 5000 5000 5000 6000 6000 6000 8000 8000 Max. Bending Length mm 4000 5000 6000 6000 7000 8000 6000 7000 Between Columns mm 3050 4050 5050 5050 6050 6200 4760 5760 Max. Shut Height mm 700 700 700 740 740 740 920 920 Slide Stroke mm 320 320 320 320 320 320 400 400 Throat Depth mm 400 400 400 400 400 400 500 500 Bolster Width mm 300 300 300 300 300 300 400 400 Down Speed mm/min 75 75 75 80 80 80 75 75 Pressing Speed mm/min 8 8 8 8 8 8 8 8 Return Speed mm/min 75 75 75 80 80 80 75 75 Back Gauge Stroke mm 700 700 700 700 700 700 1000 1000 Outline Size L mm 4500 5500 6500 6500 7500 8500 6500 7500 W mm 2700 2700 2700 2700 2700 2700 3120 3120 H mm 5000 5000 5000 5200 5200 5200 5800 5800 Weight kg 40000 45000 55000 65000 70000 76000 102000 108000 Model 800×8000 1000×6000 1000×8000 1000×12000 1200×8000 1200×12000 1600×8000 Capacity kN 8000 10000 10000 10000 12000 12000 16000 Max. Bending Length mm 8000 6000 8000 12000 8000 12000 8000 Between Columns mm 6200 4760 6200 9050 6200 9050 6200 Max. Shut Height mm 920 920 920 920 1020 1020 1020 Slide Stroke mm 400 400 400 400 400 400 400 Throat Depth mm 500 600 600 600 600 600 600 Bolster Width mm 400 400 400 400 400 400 400 Down Speed mm/min 75 70 70 70 65 65 60 Pressing Speed mm/min 8 8 8 8 7 7 7 Return Speed mm/min 75 70 70 70 65 65 60 Back Gauge Stroke mm 1000 1000 1000 1000 1000 1000 1000 Outline Size L mm 8500 6500 8500 12500 8500 12500 8500 W mm 3120 3520 3520 3520 4250 4250 4470 H mm 5800 6000 6000 6000 6750 6750 7500 Weight kg 115000 110000 135000 185000 160000 225000 215000 Model 1600×12000 2000×8000 2000×12000 Capacity kN 16000 20000 20000 Max. Bending Length mm 12000 8000 12000 Between Columns mm 9050 6200 9050 Max. Shut Height mm 1020 1020 1020 Slide Stroke mm 400 400 400 Throat Depth mm 600 600 600 Bolster Width mm 400 500 500 Down Speed mm/min 60 60 60 Pressing Speed mm/min 7 7 7 Return Speed mm/min 60 60 60 Back Gauge Stroke mm 1000 1000 1000 Outline Size L mm 12500 8500 12500 W mm 4470 4820 4820 H mm 7500 9050 9050 Weight kg 265000 270000 332000
500×4000
