CNC Metal Wire Bender China
Dongguan Xinsheng Hardware Machinery Co., Ltd.- Warranty：1 Year
- Certification：CE
- Voltage：220V,380V,440V,415V,Customized
- Application：Wire Forming
- After-Sales Service Provided：Engineers Available to Service Machinery Overseas
- Control System：CNC Control
Base Info
- Advantage：Multiple Function
- Machine Name：Multi-Axis CNC Wire Bending Machine
- Transport Package：Standard Wooden Box
- Trademark：WG
- Origin：Guangdong, China (Mainland)
Description
Basic Info.
Advantage Multiple Function Machine Name Multi-Axis CNC Wire Bending Machine Transport Package Standard Wooden Box Trademark WG Origin Guangdong, China (Mainland)Product Description
Technical Parameter| Model | GT35-10R |
| Line Diameter | 0.8-3.5mm |
| Max Line Feeding Value | 10000mm |
| Min Line Feeding Value | 0.01mm |
| Max Line Feeding Speed | 120m/min |
| Max Line Length | Unlimited |
| Axis | 10 |
| Total Power of Servo Motors | 14.2kw |
| Input Power | 380v/50hz/3ph |
| Control System | Made in Taiwan |
| Program Storage | 3000plus |
| Air Pressure | 5~6kg/cm2 |
| Probe Number | 3 |
| Dimension(L*W*H) | 140*155*180cm3 |
| Weight | 1600kg |
