CNC Hydraulic Press Brake
TENGZHOU HISING MACHINE TOOLS CO., LTD.- Automation：Automatic
- Suitable for：Carbon Steel, Stainless Steel
- Type：Press Brake
- Application：Machinery & Hardware
- Type for Cutting Machine：CNC Cutting Machine
- Type for Fold-Bending Machine：CNC Fold-Bend Machine
Base Info
- Model NO.：WC67K-20,1320,WC67K-400,4000,WC67K-125,3600
- Transport Package：WOODEN CASE
- Trademark：HISING
- Origin：China
- Production Capacity：20SETS,MONTH
Description
Basic Info.
Model NO. WC67K-20/1320/WC67K-400/4000/WC67K-125/3600 Transport Package WOODEN CASE Trademark HISING Origin China Production Capacity 20SETS/MONTHProduct Description
Feature of WC67K Series CNC Hydraulic Press Brake: Good quality with low price. For the specification of the machine, pls see the photo and the table.| Model | nominal pressure(kn) | length of working table(mm) | distance between two colums(mm) | throat depth(mm) | travel distance of back-gauge(mm) | stroke of the ram(mm) | stroke adjustment of the ram(mm) | stroke number(time/min) | max. open height(mm) | oil tank vol | motor power (kw) | Net weight | Gross weight | dimensions(mm)L*W*H |
| WC67K-20/1320 | 200 | 1320 | 1005 | 200 | 400 | 80 | 70 | 10 | 245 | 80L | 4 | 1.5 | 1.8 | 1700*1600*2100 |
| WC67K-30/1320 | 200 | 1320 | 1005 | 200 | 400 | 80 | 70 | 10 | 245 | 80L | 4 | 1.5 | 1.8 | 1700*1600*2100 |
| WC67K-40/1320 | 400 | 1320 | 1005 | 250 | 600 | 100 | 80 | 10 | 340 | 85L | 4 | 2 | 2.5 | 1700*1600*2100 |
| WC67K-63/2500 | 630 | 2500 | 2050 | 250 | 600 | 100 | 80 | 8 | 335 | 280L | 5.5 | 5 | 5.5 | 3000*1700*2350 |
| WC67K-80/2500 | 800 | 2500 | 2050 | 250 | 600 | 100 | 80 | 8 | 355 | 280L | 7.5 | 6.5 | 7 | 3000*1700*2350 |
| WC67K-80/3200 | 800 | 3200 | 2700 | 250 | 600 | 100 | 120 | 8 | 355 | 300L | 7.5 | 7.5 | 8 | 3900*1700*2450 |
| WC67K-100/2500 | 1000 | 2500 | 2050 | 320 | 600 | 150 | 120 | 8 | 415 | 280L | 7.5 | 7.5 | 8 | 3100*1800*2560 |
| WC67K-100/3200 | 1000 | 3200 | 2650 | 320 | 600 | 150 | 120 | 8 | 415 | 300L | 7.5 | 8.5 | 9 | 3900*1800*2560 |
| WC67K-100/4000 | 1000 | 4000 | 3150 | 320 | 600 | 150 | 120 | 5 | 415 | 370L | 7.5 | 9 | 10 | 4500*1800*2580 |
| WC67K-125/3200 | 1250 | 3200 | 3650 | 320 | 600 | 150 | 120 | 8 | 415 | 550L | 7.5 | 8.5 | 9 | 3900*1900*2580 |
| WC67K-125/3600 | 1250 | 3600 | 2850 | 320 | 600 | 150 | 120 | 8 | 415 | 300L | 7.5 | 8.8 | 10.5 | 3950*1900*2580 |
| WC67K-125/4000 | 1250 | 4000 | 3150 | 320 | 600 | 150 | 120 | 8 | 415 | 370L | 7.5 | 9 | 10.5 | 4700*1900*2580 |
| WC67K-140/4000 | 1400 | 4000 | 3150 | 320 | 600 | 150 | 120 | 8 | 415 | 370L | 11 | 10 | 11.5 | 4700*2250*2580 |
| WC67K-160/3200 | 1600 | 3200 | 2600 | 320 | 600 | 200 | 160 | 8 | 455 | 11 | 11 | 12 | 4100*1800*2650 | |
| WC67K-160/4000 | 1600 | 4000 | 3150 | 320 | 600 | 200 | 160 | 8 | 455 | 11 | 13 | 14 | 4800*1900*2700 | |
| WC67K-200/3200 | 2000 | 3200 | 2600 | 320 | 600 | 200 | 160 | 8 | 455 | 15 | 11.5 | 12.5 | 4200*2000*2750 | |
| WC67K-200/4000 | 2000 | 4000 | 3150 | 320 | 600 | 200 | 160 | 8 | 455 | 15 | 15 | 16 | 4800*2000*2750 | |
| WC67K-250/4000 | 2500 | 4000 | 3150 | 400 | 600 | 250 | 200 | 8 | 660 | 15 | 17 | 18 | 4800*2000*2750 | |
| WC67K-400/4000 | 4000 | 4000 | 3280 | 400 | 600 | 250 | 200 | 6 | 735 | 37 | 35 | 36 | 5000*2700*4000 |
