Metal Disk Saw Machine (Asian Type, Manual Type) GM-275f
Zhangjiagang King-Macc Machinery Manufacturing Co., Ltd.- Waterproof Rating:IPX-8
- Warranty:1-year
- Condition:New
- Certification:ISO 9001:2000, CE
- Automation:Manual
- Suitable for:Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel
Base Info
- Model NO.:GM-275F
- Type:Pipe and Tube Bending Machine
- Transport Package:Iron Frame
- Specification:Gm-Ds-275f
- Trademark:GMACC
- Origin:China
- Production Capacity:5000PCS,Year
Description
Basic Info.
Model NO. GM-275F Type Pipe and Tube Bending Machine Transport Package Iron Frame Specification Gm-Ds-275f Trademark GMACC Origin China Production Capacity 5000PCS/YearProduct Description
1. Construction MachineBed used welding pieces, imports of hydraulic systems and electric control three of fabric to complete.
2. Design Principle
Apart from the sawing machine manually by the required length feed, the other work piece clamps, feed sawing.
3. Major Performance
The machine is operated light, no noise and no dust pollution, cutting good quality internal and external incisions, no thorns, production efficiency, and the advantages of scarfed various angles
4. Configuration
(A) As a whole bed of plate welding machine are key components of a CNC machine center completed to ensure the accuracy of machine parts.
(B) Hydraulic pump: Made in Taiwan
Hydraulic valves: Made in Taiwan
(C) Electronic parts
Motor: Made in wuxi
Button switch: Made in Taiwan
Photoelectric switches and electrical: Made in Taiwan
Name | Unit | GM-DS-275F | |
Cutting Capacity(90° ) | mm | solid bar | 45 |
mmm | round tube | 80 | |
mm | square tube | 80× 80 | |
mm | rectangle | 100× 70 | |
Cutting Capacity(45° ) | mm | solid bar | 40 |
mm | round tube | 80 | |
mm | square tube | 70× 70 | |
mm | rectangle | 80× 70 | |
The motor power | KW | 1.1/1.5 | |
The rotating speed | Giri/min | 40/80 | |
The largest opening of pincers | mm | 105 | |
Saw blade size | Mm | 275 | |
weight | kg | 98 |
