• Model NO.：ZX-1625V
• Application：Paper, Plastic, Leather, Fabric
• Power Source：Electric
• Layout：Horizontal
• Item：CNC Gasket Cutting Machine Gasket Cutter Machine
• Working Area：1600*2500mm
• Rated Power：11kw
• Max. Cutting Speed：1200mm,S
• Cutting Thickness：0.1-20mm
• Cutting Accuracy：0.1mm
• Materials Fixed Model：Vacuum Adsorption
• Format Supported：Dxf, Plt, etc
• Weight：1000kg
• Transport Package：Export Wooden Case
• Specification：3300x2250x1250mm
• Trademark：ZXT
• Origin：Jinan, Shandong, China
• HS Code：8479899990
• Production Capacity：100 Sets,Month

Basic Info.

Model NO. ZX-1625V Application Paper, Plastic, Leather, Fabric Power Source Electric Layout Horizontal Item CNC Gasket Cutting Machine Gasket Cutter Machine Working Area 1600*2500mm Rated Power 11kw Max. Cutting Speed 1200mm/S Cutting Thickness 0.1-20mm Cutting Accuracy 0.1mm Materials Fixed Model Vacuum Adsorption Format Supported Dxf, Plt, etc Weight 1000kg Transport Package Export Wooden Case Specification 3300x2250x1250mm Trademark ZXT Origin Jinan, Shandong, China HS Code 8479899990 Production Capacity 100 Sets/Month

Product Description

        CNC Gasket Cutting Machine Gasket Cutter Machine Rubber Gasket Cutting System

Model	ZX-1625V
Working Area	(W*L) 1600*2500mm
Rated Power	11kw
Max. Cutting Speed	1200mm/s
No-load Speed	1500mm/s
Cutting Thickness	0.1-20mm (depending on the materials)
Cutting Accuracy	±0.1mm
Transmission Interface	Ethernet
Drive System	Servo motor, linear guide rail, rack, and pinion
Material Fixed Mode	Vacuum adsorption
Format Supported	DXF, PLT, etc
Operation Property	Online/offline operation, continuous cutting with high efficiency, 7*24 hours with zero downtime
Safety Device	An infrared sensing device, 4 emergency stop buttons, intelligent anti-collision device
Power Supply	AC 110V/220V/380V, 50/60Hz, single/three-phase
Dimension	3300x2250x1250mm
Weight	1000kg

Q: 1. How can I choose a suitable Knife cutting machine?
A: Please provide us some info, then we can recommend you the suitable machine:
1)What materials are going to be cut? Are they rolled or not? Breathable or not?
2)What's the largest size of original materials?
3)What's the thickness of materials?
4) Except for cutting, do you need more functions, like drawing, punching holes, scanning, feeding, CCD camera, etc.?

Q: 2. Can you design a machine for me depending on my requirements?
A: Of course, we will give our professional suggestions and discuss details with you for the machine which matches all the requests with the best cost performance.

Q: 3. What should I do if the machine has any problem in the future?
A: We supply online/phone technical support and door-to-door service. Anything confusing or not goes well, pls contact us the first time.

Q: 4. What's the warranty policy?
A: Standard warranty is 12 months upon delivery.
Main parts are free of charge(except consumable parts) when problems happened because of quality problems during this period.
Problems caused by wrong operate will also be well-solved, but not for free.
We also supply lifelong after-sales service. No matter when you can guarantee our best service for your machine.

Q: 5. If I don't know this machine before, how can I operate it?
A: We supply face-to-face training and provide operating video, user manual, and telephone calls to help.
It's easy to learn, one inexperienced person can learn it within one day.
