• Model NO.：GM-SB-159NCB
• Type：Pipe and Tube Bending Machine
• Transport Package：Iron Frame
• Specification：GM-SB-159NCB
• Trademark：GMACC
• Origin：China
• Production Capacity：5000PCS,Year

Basic Info.

Model NO. GM-SB-159NCB Type Pipe and Tube Bending Machine Transport Package Iron Frame Specification GM-SB-159NCB Trademark GMACC Origin China Production Capacity 5000PCS/Year

Product Description

GM-SB-159NCB is a kind of bending machine to bend under a core or no-core winding statement. To change the dies, it can bend channel profile bending.
Construction of Machine Body by welding, mechanical parts assembly, import hydraulic system, electronic control of imports of fabric to complete.

Major performance Using industrial touch screen, in English mode menu is simple, with high precision, fast, multifunctional and high degree of automation

Confutation
A) Linear guide way, made in Taiwan
Hydraulic system, have adopted a combination of import items Fuzhou, Taiwan's sole hydraulic motor-source Hydraulic Pump, made in Taiwan Hydraulic Valves, made in Taiwan Oil way board, made in Taiwan Cylinder, made in Taiwan
Double-layer laminated steel tubing used legitimately imported Taiwan Datong
B) Electronic parts Touch screen made in Taiwan
PLC made in TaiwanOther Electronic, made inTaiwan

Main  Technical  Parameters	Unit	GM-SB-159B
Max.   Bending  Capacity	mm	159× 16
Min.   Bending  Radius	mm	100
Max.   Bending  Radius	mm	800
Max.   Bending  Angle	°	190
Motor  Power  of  Oil  System	KW	22
Max.   Pressure	Mpa	160
The  Length  of  the  Machine	mm	7100
The  Width  of  the  Machine	mm	2300
The  Height  of  the  Machine	mm	1450
The  Weight  of  the  Machine	T	12
