• Model NO.：HPB-200,1600
• Type：Beading Machine
• Capacity：2000KN
• Worktable lenth：1600mm
• Pressure：30MPa
• Trval：300+400mm
• Table size：500X1550mm
• Package size：250X95X225CM
• Net weight：3600KGS
• Transport Package：Steel Pallet
• Specification：Force: 30t
• Trademark：HAVEN
• Origin：China
• HS Code：8462
• Production Capacity：50 Units,Month

Basic Info.

Model NO. HPB-200/1600 Type Beading Machine Capacity 2000KN Worktable lenth 1600mm Pressure 30MPa Trval 300+400mm Table size 500X1550mm Package size 250X95X225CM Net weight 3600KGS Transport Package Steel Pallet Specification Force: 30t Trademark HAVEN Origin China HS Code 8462 Production Capacity 50 Units/Month

Product Description

Small hydraulic press brake bending machine with CE standrad

Feature:
With the function of braking
With adjustable work table
Extremely torsion-proof steel weldment
Reliable high-accurate hydraulic system
Hydraulic press include replaceable top tools V-block and support table with stops.
Table can be lifted through a chain driven by the main cylinder
Micro-switch for traverse adjustment
Operating: Semi-automatic, fully automatic




Specification:

Model	Capacity	Worktable lenth	Pressure	Trval	Table size	Net weight
HPB-20/490	200	490	25	200+270	300x450	550
HPB-30/580	300	580	25	200+270	300x550	650
HPB-50/790	500	790	25	220+405	400x750	1100
HPB-63/790	630	790	25	220+405	400x750	1200
HPB-1010/100	1000	1010	30	250+405	460x980	1420
HPB-1010/150	1500	1010	30	250+405	460x980	1750
HPB-1010/200	2000	1010	30	300+400	500x980	2400
HPB-1010/300	3000	1010	30	300+405	700x980	4200
HPB-100/1300	1000	1300	30	300+405	420x1250	2100
HPB-150/1300	1500	1300	30	300+405	420x1250	2400
HPB-200/1300	2000	1300	30	300+400	500x1250	2800
HPB-300/1300	3000	1300	30	300+450	600x1250	4800
HPB-100/1600	1000	1600	30	250+405	420x1550	2100
HPB-150/1600	1500	1600	30	250+405	420x1550	2450
HPB-200/1600	2000	1600	30	300+400	500x1550	3600
HPB-300/1600	3000	1600	30	300+400	600x1550	5800
