Cutting & Fold-bend Machine

Home > Product > Bending Machine

CNC Press Brake/CNC Hydraulic Press Brake/Sheet Metal Press Brake/Brake Machine

Maanshan Middle Asia Machine Tools Manufacture Co., Ltd.
  • Waterproof Rating：IPX-8
  • Warranty：1-year
  • Condition：New
  • Certification：ISO 9001:2008, CE
  • Automation：Automatic
  • Worktable Length：3200mm

Base Info

  • Model NO.：WC67K125T,3200
  • Controller System：Estun E21s
  • Main Motor：Germany Siemens
  • Hydraulic Valve：Rexroth
  • Pump：Sunny
  • Ball Screw：Hiwin
  • Pipe Connector：Emb
  • Toolings：Lianmeng
  • Footswitch：Karcon
  • Electrics：Schneider
  • Transport Package：Plastic Cover
  • Specification：CE STANDARD
  • Trademark：ZYMT
  • Origin：China
  • HS Code：8462219000
  • Production Capacity：3000 Sets,Year

Description

No.Parts NameBrandBrand Location1Main motorSiemensGermany2ElectricsSchneiderFrance3Oil CylinderYuhuaMaanshan China4Seal ringNokJapan5Hydraulic valveRexrothGermany6PumpSunnyUSA7ControllerE21Nanjing China8Pipe connectorEMBGermany9Ball screwHiwinTaiwan10Controller with moveable armYES11Front and back protection fenceYES12Backgauge with ball screwYES13Backgauge travel500MM14Emergency buttonYES
CNC Press Brake/CNC Hydraulic Press Brake/Sheet Metal Press Brake/Brake Machine
CNC Press Brake/CNC Hydraulic Press Brake/Sheet Metal Press Brake/Brake Machine

Other standard equipments:
Segmented upper punch die 1set
Lower die in one piece
Stop fingers 3
Front supporting arms 2
Emergency stop button;
Back, left and right safty fence
Foundation bolts 1set
Manuals and diagram 1book

WC67K Series Technical Parameters:TypeNominal Force
(KN)Worktable Length
(mm)Poles Distance
(mm)Throat Depth
(mm)Slider Travel
(times/min)Max Open
(mm)Power
(kw)40T/2200400220018502301003205.540T/2500400250018502301003205.550T/2500500250018502301003205.563T/2500630250019002501003205.563T/3200630320025602501003205.580T/2500800250019903001003207.580T/3200800320025603201003507.580T/4000800400032003201003507.5100T/25001000250019003201203507.5100T/32001000320026003201504007.5100T/40001000400032003201504007.5125T/320012503200260032015040011125T/400012504000320032015040011160T/320016003200258032020046011160T/400016004000290032020046011160T/500016005000390032020046011160T/600016006000490032020046011200T/320020003200248032020046011200T/400020004000290032020046011200T/500020005000390032020046011200T/600020006000490032020046011250T/320025003200245040025059018.5250T/400025004000290040025059018.5250T/500025005000390040025059018.5250T/600025006000490040025059018.5300T/320030003200245040025059022300T/400030004000290040025059022300T/500030005000390040025059022300T/600030006000490040025059022400T/320040003200240040025059030400T/400040004000290040025059030400T/500040005000390040025059030400T/600040006000490040025059030500T/500050005000390040025059045500T/600050006000490040032059045600T/500060005000290040032059055600T/600060006000490040032059055

Company Introduction:
1.Maanshan Middle Asia Machine Tools Manufacture Co.,Ltd founded in 2001.
2.Total number of emploee: 500
3.All kinds of sophisticated equipment more than 100 sets.
4.Production plant area:60,000.
5.Whole factory is controlled by ERP-Enterprise Resource Plan.
6.CE/SGS/ISO9001 certification.
We are producing below ranges of machines:
1.NC/CNC Press Brake
2.NC/CNC Shearing Machine
3,Rolling Machine
4.Iron Worker
5.Power Press
6.Hydraulic Press
