- Model NO.:WC67K
- Material / Metal Processed:Stainless Steel
- Bend Thickness:5mm
- After Sale Service Provided:Engineers Available to Service Machinery Overseas
- Motor( Kw):7.5
- Throat(mm):320
- Open Height(mm):400
- Stroke(mm):150
- Application:Machinery & Hardware
- Type for Fold-Bending Machine:Hydraulic Fold-Bend Machine
- Transport Package:with Plastic Bag or According to′ Requirements
- Specification:CE
- Trademark:Hydraulic bending machine WC67Y 500T,6000
- Origin:China
- HS Code:8462299000
- Production Capacity:2000 Set,Year
Model | Nominal Pressure(KN) | Length of Table | Distance between columns | Throat Depth | Stroke | Open Height | Main Motor(KW) | Overall Dimensions L*W*H(mm) |
(mm) | (mm) | (mm) | (mm) | (mm) |
40T/2200 | 400 | 2200 | 1850 | 230 | 100 | 320 | 5.5 | 2200*1200*1900 |
40T/2500 | 400 | 2500 | 1850 | 230 | 100 | 320 | 5.5 | 2500*1200*1900 |
50T/2500 | 500 | 2500 | 1850 | 230 | 100 | 320 | 5.5 | 2500*1200*1900 |
63T/2500 | 630 | 2500 | 1900 | 250 | 100 | 320 | 5.5 | 2500*1300*2210 |
63T/3200 | 630 | 3200 | 2560 | 250 | 100 | 320 | 5.5 | 3200*1300*2100 |
80T/2500 | 800 | 2500 | 1990 | 300 | 100 | 320 | 7.5 | 2500*1400*2300 |
80T/3200 | 800 | 3200 | 2560 | 320 | 100 | 350 | 7.5 | 3200*1500*2300 |
80T/4000 | 800 | 4000 | 3200 | 320 | 100 | 350 | 7.5 | 4000*1500*2400 |
100T/2500 | 1000 | 2500 | 1990 | 320 | 120 | 350 | 7.5 | 2500*1600*2400 |
100T/3200 | 1000 | 3200 | 2600 | 320 | 150 | 400 | 7.5 | 3200*1600*2600 |
100T/4000 | 1000 | 4000 | 3200 | 320 | 150 | 400 | 7.5 | 4000*1600*2600 |
125T/3200 | 1250 | 3200 | 2600 | 320 | 150 | 400 | 11 | 3200*1600*2600 |
125T/4000 | 1250 | 4000 | 3200 | 320 | 150 | 400 | 11 | 4000*1600*2600 |
160T/3200 | 1600 | 3200 | 2580 | 320 | 200 | 460 | 11 | 3200*1700*2700 |
160T/4000 | 1600 | 4000 | 2900 | 320 | 200 | 460 | 11 | 4000*1700*2800 |
160T/5000 | 1600 | 5000 | 3900 | 320 | 200 | 460 | 11 | 5000*1900*3100 |
160T/6000 | 1600 | 6000 | 4900 | 320 | 200 | 460 | 11 | 6300*1900*3200 |
200T/3200 | 2000 | 3200 | 2480 | 320 | 200 | 460 | 11 | 3200*1950*2800 |
250T/3200 | 2500 | 3200 | 2450 | 400 | 250 | 590 | 18.5 | 3250*2000*3200 |
250T/4000 | 2500 | 4000 | 2900 | 400 | 250 | 590 | 18.5 | 4000*2000*3400 |
250T/5000 | 2500 | 5000 | 3900 | 400 | 250 | 590 | 18.5 | 5000*2000*3400 |
250T/6000 | 2500 | 6000 | 4900 | 400 | 250 | 590 | 18.5 | 6000*2000*3400 |
300T/3200 | 3000 | 3200 | 2450 | 400 | 200 | 590 | 22 | 3500*2000*3450 |
300T/4000 | 3000 | 4000 | 2900 | 400 | 250 | 590 | 22 | 4000*2000*3450 |
300T/5000 | 3000 | 5000 | 3900 | 400 | 250 | 590 | 22 | 5000*2000*3450 |
300T/6000 | 3000 | 6000 | 4900 | 400 | 250 | 590 | 22 | 6000*2000*3450 |
400T/3200 | 4000 | 3200 | 2400 | 400 | 250 | 590 | 30 | 3200*2180*3400 |
400T/4000 | 4000 | 4000 | 2900 | 400 | 250 | 590 | 30 | 4000*2180*3400 |
400T/5000 | 4000 | 5000 | 3900 | 400 | 250 | 590 | 30 | 5000*2180*3500 |
400T/6000 | 4000 | 6000 | 4900 | 400 | 250 | 590 | 30 | 6000*2180*3800 |
500T/5000 | 5000 | 5000 | 3900 | 400 | 250 | 590 | 45 | 5050*3500*3700 |
500T/6000 | 3000 | 6000 | 4900 | 400 | 320 | 590 | 45 | 6050*3500*3700 |
600T/4000 | 6000 | 4000 | 2900 | 400 | 320 | 590 | 55 | 4050*4500*3700 |
600T/6000 | 6000 | 6000 | 4900 | 400 | 320 | 590 | 55 | 6050*4500*3700 |
Remark:Parameters change without notice. All the sizes above models are suitable for tandem. |
Packaging & Shipping (1)before packing,the machine tool will be testing for 48 hours to ensure all the equipment is 100% qualitied.
(2)before loading,stable package,professional and skilled loader reduce damage of product during transport.
(3)after loading,our professional documentary staff will follow the order till the product departs from port.
