• Model NO.：W11-20x3200
• Type：Roller-Bending Machine
• Driver：Motor+ Gear
• Application：Machinery & Hardware, Textiles, Chemical
• Type for Cutting Machine：Roling Machine
• Type for Fold-bending Machine：Mechanical Rolling Machine
• Transport Package：Steel Plate
• Specification：ISO 9001: 2000
• Trademark：HAVEN
• Origin：China
• HS Code：84622990
• Production Capacity：200 Units, Month

Basic Info.

Model NO. W11-20x3200 Type Roller-Bending Machine Driver Motor+ Gear Application Machinery & Hardware, Textiles, Chemical Type for Cutting Machine Roling Machine Type for Fold-bending Machine Mechanical Rolling Machine Transport Package Steel Plate Specification ISO 9001: 2000 Trademark HAVEN Origin China HS Code 84622990 Production Capacity 200 Units/ Month

Product Description

W11-20X3200 Mechanical Type Rolling and Bending Machine



1.Main functions:
The machine adopts 3-roller symmetrical structure with the upper roller moving vertically in the center between the two lower rollers, which is achieved through the drive of the screw, the nut, the worm and the lead screw, the two lower rollers rotates and provides the plate materials with torque through the engagement of the output gear of the moderator with the ear of the lower rollers, the disadvantage of the machine is that the ends of the plate materials need to have the help from other equipment for pre-bending.

Model	Max. thickness	Max. width	Bending speed	Workpiece Min. Dia.	Top roller Dia	Bottom roller Dia.	Dis. bottom rollers	Main motor
W11-4x3000	4	3000	5	450	140	160	220	5.5
W11-6x2000	6	2000	5	430	170	170	220	5.5
W11-6x2500	6	2500	4	550	220	170	250	7.5
W11-6x3000	6	3000	4	600	240	190	280	7.5
W11-8x2000	8	2000	5	480	190	170	220	5.5
W11-8x2500	8	2500	4	600	240	180	280	7.5
W11-8x3000	8	3000	4	600	240	180	280	11
W11-10x2000	10	2000	4	550	220	170	250	7.5
W11-10x3000	10	3000	4	650	260	220	340	11
W11-12x2000	12	2000	4	600	240	180	280	7.5
W11-12x2500	12	2500	4	650	260	220	320	11
W11-12x3000	12	3000	4	700	280	24	360	15
W11-16x1500	16	1500	5	600	240	180	280	7.5
W11-16x2000	16	2000	4	650	260	220	320	11
W11-16x2500	16	2500	4	700	280	240	360	15
W11-16x3200	16	3200	4	850	340	280	440	18.5
W11-20x2000	20	2000	4	700	280	240	360	11
W11-20x2500	20	2500	4	850	340	280	440	18.5
W11-20x3000	20	3000	4	930	370	280	440	22
W11-25x2000	25	2000	4	850	340	280	440	18.5
W11-25x2500	25	2500	4	930	370	280	480	22
W11-30x2000	30	2000	4	930	370	280	480	22

2. Our Services
1: Response in time after getting customer's claim
1: Provide solution in 1 day
2: Usually solve problem within 2 days
2. For big machine, Installation Service is available as per customer's requirement


3. Training Service
Our technician is available to your factory and offer training of how to use our machines. As well, you may send your technician to our company to learn how to operate machines.


4. Quality Guarantee
We guarantee the quality of machine (e.g. processing speed and working performance is the same as the data of samples making). We sign the agreement with detailed technical data.
We arrange final test before shipment. We run the machine for a few days, and then use customer's materials for test. After making sure machine is the best performance, then make shipments.
