QC11y Hydraulic Type Guillotine Plate Cutting Machine
Shanghai YingXin World Machinery Co., Ltd.- After-sales Service:Available
- Automation:Automatic
- Certification:CE, ISO 9001:2000
- Condition:New
- Warranty:1 Year
- Plate Cutting Machine:Hydraulic Shearing Machine
Base Info
- Model NO.:QC11Y
- Power Source:Hydraulic Oil
- Control Type:Nc Control
- Transport Package:Container
- Specification:CE
- Trademark:World
- Origin:Jiangsu Danyang
- HS Code:87019011
- Production Capacity:2000
Description
Basic Info.
Model NO. QC11Y Power Source Hydraulic Oil Control Type Nc Control Transport Package Container Specification CE Trademark World Origin Jiangsu Danyang HS Code 87019011 Production Capacity 2000Product Description
QC11Y hydraulic type guillotine plate cutting machineFeatures:
1)Entirely steel welded frame, treated to release stress by tempering.
2)Hydraulic drive, return of knife beam is smooth and prompt by nitrogen cylinder.
3)Adopts rolling guideway to raise shear precision.
4)The stroke of knife beam can be adjusted.
5)With counter.
6)Shearing angle can be adjusted.
7)With protection fence.
Specifications
Items | unit | QC11Y-6x2500 | QC11Y-6x3200 | QC11Y-6x4000 |
Max. cutting thickness | mm | 6 | 6 | 6 |
Max. cutting width | mm | 2500 | 3200 | 4000 |
Tensile strength of plate to be cut | N/mm2 | 450 | 450 | 450 |
Cutting angle | deg | 0.5-1.5 | 0.5-1.5 | 0.5-1.5 |
Travel distance of back gauge | mm | 20-550 | 20-550 | 20-600 |
Throat depth | mm | 150 | 150 | 150 |
Stroke speeds | spm | 16-26 | 12-22 | 10-20 |
Main motor | kW | 7.5 | 7.5 | 7.5 |
Length | mm | 3000 | 3700 | 4800 |
Width | mm | 1500 | 1650 | 1650 |
Height | mm | 2000 | 2050 | 2250 |
Items | unit | QC11Y-8x2500 | QC11Y-8x3200 | QC11Y-8x4000 |
Max. cutting thickness | mm | 8 | 8 | 8 |
Max. cutting width | mm | 2500 | 3200 | 4000 |
Tensile strength of plate to be cut | N/mm2 | 450 | 450 | 450 |
Cutting angle | deg | 0.5-2 | 0.5-2 | 0.5-2 |
Travel distance of back gauge | mm | 20-600 | 20-600 | 20-600 |
Throat depth | mm | 150 | 150 | 150 |
Stroke speeds | spm | 14-25 | 12-20 | 10-20 |
Main motor | kW | 11 | 11 | 11 |
Length | mm | 3040 | 3860 | 4800 |
Width | mm | 1700 | 1700 | 1800 |
Height | mm | 2150 | 2350 | 2480 |
Items | unit | QC11Y-10x2500 | QC11Y-10x3200 | QC11Y-10x4000 |
Max. cutting thickness | mm | 10 | 10 | 10 |
Max. cutting width | mm | 2500 | 3200 | 4000 |
Tensile strength of plate to be cut | N/mm2 | 450 | 450 | 450 |
Cutting angle | deg | 0.5-1.5 | 0.5-1.5 | 0.5-1.5 |
Travel distance of back gauge | mm | 20-600 | 20-600 | 20-600 |
Throat depth | mm | 150 | 150 | 150 |
Stroke speeds | spm | 12-20 | 10-20 | 10-18 |
Main motor | kW | 11 | 15 | 15 |
Length | mm | 3040 | 3860 | 4800 |
Width | mm | 1700 | 1700 | 1800 |
Height | mm | 2150 | 2350 | 2480 |
