• Model NO.：CHM Series
• Transport Package：Fumigated Wooden Case
• Specification：CE
• Trademark：Sunworld
• Origin：China Shanghai
• HS Code：84411000
• Production Capacity：30 Sets, Month

Basic Info.

Model NO. CHM Series Transport Package Fumigated Wooden Case Specification CE Trademark Sunworld Origin China Shanghai HS Code 84411000 Production Capacity 30 Sets/ Month

Product Description

Performance and Characteristics

This machine is suitable for cutting the large coil packaging material, such as the paper, paper plastic complex material and color printing complex material, etc. This machine is widely used for application in the industries of paper processing and printing packaging.

With development and competition of paper products process industry and

printing industry, rolling paper cutting machine has become one of the in

dispensable equipments in paper products process industry and printing

industry.

Some spare parts like electric are made in Europe, America and Japan, etc. Making such machine become much simple operation, convenience repair with the technique of both computer well controlling and machine be combined, even more, it ensure keeping of precision and steady of machine when running with high speed.

It is widely adopted in paper products process industry and printing





Main Technical Parameters

Model	CHM-1400	CHM-1700	CHM-1900
Accuracy of cutting	±0.5mm	±0.5mm	±0.5mm
Max. speed	300m/min	300m/min	300m/min
Length range of cutting	450-1450mm	450-1450mm	450-1450mm
Max. width of cutting	1400mm	1700mm	1900mm
Max. diameter of material	¢1600mm	¢1600mm	¢1600mm
Cutter load	550g/ m2	550g/m2	550g/m2
Max. thickness of cutting	600gsm	600gsm	600gsm
Weight	13000kg	15000kg	17000kg
Height of paper-piling	1300mm	1300mm	1300mm
Power supply	AC380V/220V×50Hz	AC380V/220V×50Hz	AC380V/220V×50Hz
Overall dimension(LxWxH)	11500x4000x2200	11500x4300x2200	11500x4500x2200
Total power	22Kw	25Kw	28Kw
