Fully Automatic Curving Machine for Standing Seam Cuveing Machine

Xiamen Xinhonghua Machinery Co., Ltd.
  • Warranty：1-year
  • Condition：New
  • Certification：SGS
  • Automation：Automatic
  • Suitable for：Copper, Aluminum, Alloy
  • Type：Roll Forming Machine

Base Info

  • Model NO.：YX65-300-600
  • Main Motor Power：4kw
  • Motor Power for Adjusted：0.75kw
  • Forming Steps：4
  • Curving Thickness：0.6-1.0mm
  • Min. Convex Curved：1m
  • Min. Concave Curved：5m
  • Curving Speed：16-20m,Min
  • After-Sales Provided：Engineers Available to Service Machinery Overseas
  • Use Widely：Easy to Maintenance,Work Flexible
  • Delivery Time：Delivery Immediately After The Machine Is Assemble
  • Transport Package：Standard Package
  • Specification：SGS
  • Trademark：XHH
  • Origin：Xiamen, China
  • HS Code：84552290
  • Production Capacity：20sets,Month

Description


Size1500*800*2000mmWeight1500KGSMotor power4kwVoltage380V/50HZ/3PHMotor power for adjustment0.75KWForming steps4Working speed10-16m/minMaterial width300-600mmCurved thickness for steel roof0.6-0.8mmCurved thickness for aluminum Roof0.7-1.0mmMax. width of tapered roofing to curved500mmMin. width of tapered roofing to curved250mmMin. curved radius for tapered roofingConvex curved 10m, concave curved 12mMin. curved radius for steel roofingConvex curved 6m, concave curved 8mMin. curved radius for aluminum roofingConvex curved 2m, concave curved 5m
