• Model NO.：CNC Series
• Type for Fold-bending Machine：CNC Fold-bend Machine
• Transport Package：Sea Worthy Packing
• Specification：CE
• Trademark：Acemachinetools
• Origin：China
• HS Code：84622990
• Production Capacity：100sets,Month

Basic Info.

Model NO. CNC Series Type for Fold-bending Machine CNC Fold-bend Machine Transport Package Sea Worthy Packing Specification CE Trademark Acemachinetools Origin China HS Code 84622990 Production Capacity 100sets/Month

Product Description

CNC Single-Head press brake/Bending Machine (CNC 63/76/89/100/114/120)


Product Number: 1112146116
Product Name: CNC Single-Head Bending Machine
Model: CNC 63/76/89/100/114/120
Series: CNC-3A-1S Series

Product Description
CNC Single-Head Bending Machine
Model GM-SB 63/76/89/100/114/120 CNC-3A-1S Series:

Characteristics of Pipe Bending Machine:
KING-MACC Full-Auto pipe bending machine adopts advanced industrial computer controller or color touch screen. It can easily produce precision bending parts which you need. It will provide you modernizational efficiencyFactory with the most advanced and complete bending technology by its most reliable controlling function. Our Machine will meet your needs with best quality, most accuracy, highest speed, most durability and safe as well As a whole set of service.
Characteristics if CNC Series (Economic Type) Single-Head Bending Machine
Characteristics of CNC Series Economic Touch type Single-layer Die Machine:

(1)It has Y(feeding material), B(rotating pipe), C(bending pipe) three-axis electric servo motor driving.

(2)C-axis(bending pipe)servo motor driving concealed type and direct driving design.

(3)The speed is fast and accurate. It is suitable for producing small tube elements, such as complex parts of
Automobile or air conditions.

Main Technical Parameter	Unit	63CNC	76CNC	89CNC	100CNC	114CNC	120CNC
Max. Bending Capacity	mm	63×3	76×3	89×4	100×6	114×4	120×3
Bending Radius Region	mm	25-300	30-350	40-400	40-400	40-450	40-450
Bending Angle Region	Degree	0-190	0-190	0-190	0-190	0-190	0-190
Effective Length Over Mandrel	mm	2600	2600	3200	3200	3500	3500
Oil Pressure System Motor	kw	5.5	5.5	7.5	7.5	11	11
Max. Pressure	kg/cm	160	160	160	160	160	160
Machine Dimension	mm	5000×1200×1350	5000×1200×1350	5500×1350×1200	5500×1350×1200	6500×1350×1300	6500×1350×1300
Machine Weight	kg	3000	3500	4800	5000	5500	6000
