50mm Steel Bar Bender /Wrought Iron Bending Machine

Jurong Topall Machinery Co., Ltd.
  • Condition：New
  • Certification：ISO 9001:2000
  • Automation：Manual
  • Type：Pipe and Tube Bending Machine
  • Power Type：380V,3h,50Hz or 220V,3h,60Hz
  • Warranty：12 Month

Base Info

  • Model NO.：GW50
  • Application：Machinery & Hardware
  • Type for Cutting Machine：Flame Cutting Machine
  • Type for Fold-Bending Machine：Manual Fold-Bend Machine
  • Type for Pipe and Tube Bending Machine：Electric Hydraulic Pipe Bender
  • Transport Package：1*20gp Container: 24 Units
  • Specification：CE ,ISO
  • Trademark：TOPMAC
  • Origin：Zhengjiang, Jiangsu, China
  • HS Code：84622990
  • Production Capacity：2000 Unit ,Month

Description

BENDING CAPACITY6-50 mm (ob≤450N/mm2)6-40 mm (ob ≤650N/mm2)Model GW50GW50OPERATIONAutomaticManualTYPE OF MOTORYEJ 100L2-4 (Brake motor)Y100L2-4MOTOR POWER4 KW-4P4 KW-4PHORSE POWER5 HP5 HPMOTOR ROTATION SPEED1420 R/min1420 R/minSPEED OF WORKING DISK9 R/min9 R/minNOISE VALUE (1m away)≤80dB(A)≤80dB(A)WEIGHT466 Kg.476 Kg.DIMENSIONS (L×W×H)1040×820×800 mm1040×820×800 mm
