CNC Single-Head Bending Machine Multi-Layer (with Pushing Bending Series)
ACE Machine Tools Co., Ltd.- Automation：Automatic
- Type：Beading Machine
- Type for Cutting Machine：CNC Cutting Machine
- Type for Fold-bending Machine：CNC Fold-bend Machine
- Application：Machinery & Hardware
- Transport Package：Sea Worthy Packing
Base Info
- Model NO.：63,76,89,100,114,120
- Origin：China
Description
| Main Technical Parameter | Unit | 63CNC | 76CNC | 89CNC | 100CNC | 114CNC | 120CNC |
| Max. Bending Capacity | mm | 63×3 | 76×3 | 89×3 | 100×3 | 114×3 | 120×3 |
| Max. Push Bending Capacity | mm | 63×3 | 76×3 | 89×3 | 100×3 | 114×3 | 120×3 |
| Bending Radius Region | mm | 25-300 | 30-350 | 40-400 | 40-400 | 40-450 | 40-450 |
| Bending Angle Region | Degree | 0-190 | 0-190 | 0-190 | 0-190 | 0-190 | 0-190 |
| Max. Bending Radius of Push Bending | mm | 6D-∞ | 6D-∞ | 6D-∞ | 6D-∞ | 6D-∞ | 6D-∞ |
| Effective Length Over Mandrel | mm | 2600 | 2600 | 3000 | 3000 | 3200 | 3200 |
| Oil Pressure System Motor | kw | 5.5 | 5.5 | 7.5-11 | 7.5-11 | 11.-15 | 11.-15 |
| Max. Pressure | kg/cm | 160 | 160 | 160 | 160 | 160 | 160 |
| Machine Dimension | mm | 5000×1200×1350 | 5000×1200×1350 | 5500×1350×1200 | 5500×1350×1200 | 6500×1350×1300 | 6500×1350×1300 |
| Machine Weight | kg | 3500 | 3500 | 5000 | 5500 | 5800 | 5800 |
