• Model NO.：GM-28CNC-3A-1S
• Type：Cnc Bending Machine
• Transport Package：Iron Frame
• Specification：4000X650X1300mm
• Trademark：GMACC
• Origin：China
• HS Code：8462219000
• Production Capacity：5000PCS,Year

Basic Info.

Model NO. GM-28CNC-3A-1S Type Cnc Bending Machine Transport Package Iron Frame Specification 4000X650X1300mm Trademark GMACC Origin China HS Code 8462219000 Production Capacity 5000PCS/Year

Product Description

GM-SB-28CNC Full-Auto Numerical Control Single-Head Bending Machine
Model:SB28×3A×1S

• Machine Characteristics
• SB-CNC Series numerical control single-head pipe bending machine is the product from the combination with our technology and advanced Italian technology, integrated with machine, hydraulic, and electricity. This series adopt VDU touch screen operating panel, which can input, store, and display various bending data and order. Y, B, C three coordinatesofmotions under precision control by industrial computer can realize full-auto mandrel on or mandrel off rapid bending, CNC machine also with advanced functions, such as components bending springback compensation, errors self diagnose alarm, memory store after power off, automatic lubrication and safety protection.Pipe rotating (B axis) and pipe feeding(Y axis) are both driven by servomotor.Pipe bending(C axis) is hydraulic.

• Main Technical Parameter

Name	Unit	Parameter
Max. Bending Capacity	mm	¢28*2
Bending Radius Range	mm	20-180
Max. Bending Angle	°	190°
Bending Speed	°/sec	180
Turning Speed	°/sec	280
Feeding Speed	mm/sec	1000
Bending Precision	°	±0.10
Turning Precision	°	±0.10
Feeding Precision	mm	±0.10
Turning Servomotor Power	kW	0.4
Feeding Servomotor Power	kW	0.4
Through effective distance	mm	3200
L*W*H (Packaging Dimension)	mm	2900*800*1500
Weight	T	1.0



• Configuration of Hydraulic and Electronic Control System

Name	Manufacturer
Hydraulic Motor	Germany Siemens( Imported)
Hydraulic Pump	Taiwan Hydromax(Imported)
Hydraulic Valve	Japan Yuken(Imported)
Oil way Board	Taiwan Shanghong (Imported)
Cylinder	Shanghai Jingsheng
Oil tube	Suzhou Kejia
Touch screen	Taiwan Weinview(Imported)
PLC	Japan Mitsubishi(Imported)
Servo Motor	Japan Mitsubishi(Imported)
Angle controller	Japan Nemicon(Imported)
Switch power	Wenzhou Changjiang
Contactor	German SCHNEIDER(Imported)
