48mm to 90mm Manual Steel Anchor Chain Making Machine Chain Forming Machine
Dele Electrical (Hangzhou) Co., Ltd.- After-sales Service：Support
- Waterproof Rating：IPX-8
- Warranty：1-year
- Condition：New
- Certification：CE
- Automation：Automatic
Base Info
- Model NO.：DL-48W
- Suitable for：Alloy, Carbon Steel, Stainless Steel
- Type：Chain Welding
- Product Name：48mm to 90mm Manual Steel Anchor Chain Making Mach
- Size：48mm to 90mm
- Minimum Diameter：37mm
- Maximum Diameter：70mm
- Voltage：380V 50,60Hz
- Arm Length：7200mm
- Lead Time：5months
- Transport Package：Polywood Case Packing
- Specification：48-90mm
- Trademark：Delelift
- Origin：China
- Production Capacity：20sets,Year
Description
Basic Info.
Model NO. DL-48W Suitable for Alloy, Carbon Steel, Stainless Steel Type Chain Welding Product Name 48mm to 90mm Manual Steel Anchor Chain Making Mach Size 48mm to 90mm Minimum Diameter 37mm Maximum Diameter 70mm Voltage 380V 50/60Hz Arm Length 7200mm Lead Time 5months Transport Package Polywood Case Packing Specification 48-90mm Trademark Delelift Origin China Production Capacity 20sets/YearProduct Description
These divide dinto four parts:chain bending machine,welding machine,burring machine and rotary chain conveying machine.Each part is equipped with independent electrical control and hydraulic drive system,water cooling system,centralized lubrication system,the chain braiding machine also includes 1000K Winter mediate frequency heating power supply and induction heater,bar automatic lifting,mechanical arm feeding,hot material automatic conveying device.list:1000K Wheat machine(IGBT),bending machine,PLC power cotrol,Hydraulic system,automatic feeding and feeding device.(1)The machine is made upofcasting parts,forging sands tructural parts.The main partis made of 35# cast steel and castasa whole.(2)This machine is suitable for circular chain and compact chain.After heating ther od,it adopt sone-time forming chain braided mode.The core mould is compose do fupper and lower parts,the lower core mould is fixed,and
the upper core mould can be moved,which can be moved horizontally under the push of hydraulic cylinder
Inter mediate frequency heating furnace can be used for chain carbon steel and stainlesssteel material heating,with temperature measuring device(sensoranddisplay),can According to the need to setthe constant temperature control mode,the discharging mode is rod series mode.
