One-Way Servo Pump CNC Press Brake Bending Machine Pbc-160t/4100mm
Shanghai Lejia CNC Machine Co., Ltd.- Waterproof Rating：IPX-8
- Warranty：1-year
- Condition：New
- Certification：ISO 9001:2000, ISO 9001:2008, CE
- Automation：Automatic
- Suitable for：Plastic, Rubber, Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel
Base Info
- Model NO.：PBC-160,4100
- Type：Press Brake
- Transport Package：Applicable for Shipment
- Specification：CE
- Trademark：sljs
- Origin：China
- HS Code：84622990
- Production Capacity：500 PCS Per Year
Description
No.
Name
Specification
Unit
PBC-160/4100-4S
1
Normal pressure
1600
kN
2
Length of worktable
4100
mm
3
Thickness of worktable
80
mm
4
Distance between uprights
3600
mm
5
Ram Y axis stroke
265
mm
6
Die setting height
585
mm
7
Throat depth
410
mm
8
CNC axis
4S(Y1,Y2,X,R,S)
9
Ram Y axis speed
Approach
160
mm/s
Working
14
mm/s
Return
150
mm/s
10
Back gauge
X axis
Stroke
500
sheet metal size
0-950
mm
Max.speed
400
mm/s
Repeat positioning accuracy
0.03
mm
11
Ram repeat positioning accuracy
0.01
mm
11
Overall dimension
L
4630
mm
W
1600
mm
H
3025
mm
12
Power supply
12
kW
13
Weight
12300
kg
Y1,Y2---Control ram movement
X---Control back gauge front and rear movement
R-- Control back gauge up and down movement
S--- WILA mechanical compensation crowning system
Machine structure
1,Outline feature
HIWIN/PMI,Taiwan
Ball screw
11
Seals of oil cylinder
SKF,Swizerlands
12
Proximity switch
CONTRINEX,Swizerlands
13
Single/double air switch
SIEMENS,Germany
14
AC contactor
15
Button
SCHNEIDER,France
16
Terminal
WAGO/Phoenix,Germany
17
Oil tube connector
EMB,Germany
Optional parts:
