Electric Bending Machine Round Square Stainless Steel Tube Using in Greenhouse Fence Gate
Quanzhou Minze Hardware Machinery Equipment Co., Ltd- Waterproof Rating:IPX-0
- Warranty:1-year
- Condition:New
- Automation:Semi-Automatic
- Suitable for:Copper, Aluminum, Alloy, Stainless Steel
- Type:Roller-Bending Machine
Base Info
- Model NO.:MZ09
- Transport Package:Wooden Package
- Specification:750*500*980
- Trademark:Minze
- Origin:China
- Production Capacity:1000set,Year
Description
Basic Info.
Model NO. MZ09 Transport Package Wooden Package Specification 750*500*980 Trademark Minze Origin China Production Capacity 1000set/YearProduct Description
This product is suitable for the processing and bending of round and square tube,such as vegetable greenhouse, galvanized pipe fence, stainless steel anti-theft net, Iron art gate, window grille. The bending pressure power from motor drive, and more information for how to use about this machine can refer to the video.
The feature of electric bending machine
1. Change mold easily, can bend round and square pipe.
2. The bending shape radian can be control.
Model | MZ-630 | MZ-760 |
Round pipe diameter | 19 22 25 32 38 51 63 MM | 19 22 25 32 38 51 63 76 MM |
Square pipe diameter | 20 25 30 40 50 MM | 20 25 30 40 50 60 MM |
Motor power | 1.5KW | 2.2KW |
Bending pipe thickness | 0.5-1.5MM | 0.5-3.5MM |
Voltage & Frequency | 220V/380V 50HZ | 220V/380V 50HZ |
Dimension(L*W*H) | 500*750*980 | 720*540*960 |
Weight | 135 kg | 180kg |
Electric stainless steel pipe bending machine constitutes by Clip pipe device(in-built Clip pipe mould),bending working device,including type wheel and exterior rotary device,bending power plsnt motor,speed changing box and so on,CNC control device and so on.
Pedal the foot switch at first,Motor rotate clockwise use the triangle by the gearbox to slow down,and then when use the main output shaft of the gearbox to driven the bending work device rotation to the desired position,the motor automatic reversal,when the bending work device back to the aircraft stands,stop trip switch off the circuit.the motor stop working is complete.
1. Do you provide any training to ensure that our users can operate the machine well? Our machine is stable and easy to operate, we will send you operation manual, running videos, online training, and if there is something goes wrong , you can call us, video-chat ,email us,we will give solutions within 36 hrs.
2. How about the shipping cost?
The cost of shipping depends on the method you choose to obtain the goods. Express delivery is usually the fastest method, but it is also the most expensive method. Shipping is the best solution for large quantities. For the exact shipping cost, we can only provide you with detailed information after knowing the quantity, weight and dimension.
3. Do you have Stock productions to sell?
Yes, of course. But we also offer OEM service. The mold is customized, Please send us some drawing.
What information do you want to know if i want to get a quotation?
a). The application for your products.
b). Special package methods if you needs.
4. Do you inspect the finished products?
Yes. Each step of products will be carried out inspection by QC department until shipping
5. What's the delivery time and payment term?
Normally Around 5~15days. Accepted Payment term: T/T, Cash; if it is less than 5000 US dollars, Western Union remittance shall be adopted. Accepted Delivery Terms: FOB,CFR, CIF, EXW.
