• Advantage：Multiple Function
• Machine Name：Multi-Axis CNC Wire Bending Machine
• Transport Package：Standard Wooden Box
• Trademark：WG
• Origin：Guangdong, China (Mainland)

Basic Info.

Advantage Multiple Function Machine Name Multi-Axis CNC Wire Bending Machine Transport Package Standard Wooden Box Trademark WG Origin Guangdong, China (Mainland)

Product Description

Technical Parameter


Model	GT100-12R
Line Diameter	4.0-10.0	mm
Max Line Feeding Value	10000	mm
Min Line Feeding Value	0.01	mm
Max Line Feeding Speed	60	m/min
Max Line Length	Unlimited
Axis	12
Total Power of Servo Motors	86.3	kw
Input Power	380/50/3	v/hz/ph
Control system	Made in Taiwan
Program Storage	3000	plus
Air Pressure	5~6	kg/cm2
Probe Number	3
Overall length	4200	mm
Overall width	2350	mm
Overall height	2580	mm
Weight	12000	kg

SPECIFICATIONS:

1) Flexible external twisting head with faster speed and more twisting angle.
2) Adopting Japanese Sanyo Denki servo motor and Taiwanese controller screen display.
3) Camless design, flexible in adjusting and great in precision.
4) Running in a high automatization and intellectualization, no pollution.
5) Bilingual interface, easy to operate.
