• Model NO.：PSH
• Type：Press Brake
• Product Name：Da52s Control Stainless Steel CNC Press Brake
• Extra Services：Forming
• Electrical Component：Schneider
• Sealing Element：Nok
• Hydraulic Valve：Rexroth
• Motor：Siemens Beide
• Application：Metal Sheet Bending
• Safety Proteection：Protective Guard
• Control System：Da52s
• Color：Customizable
• Transport Package：Plastic Film, Wooden Package, or as Requirement.
• Specification：3690*1750*1680
• Trademark：Durmark
• Origin：China Anhui
• HS Code：8462219000
• Production Capacity：60

Basic Info.

Model NO. PSH Type Press Brake Product Name Da52s Control Stainless Steel CNC Press Brake Extra Services Forming Electrical Component Schneider Sealing Element Nok Hydraulic Valve Rexroth Motor Siemens Beide Application Metal Sheet Bending Safety Proteection Protective Guard Control System Da52s Color Customizable Transport Package Plastic Film, Wooden Package, or as Requirement. Specification 3690*1750*1680 Trademark Durmark Origin China Anhui HS Code 8462219000 Production Capacity 60

Product Description

DA52S Control Stainless Steel CNC Press Brake With Cheap Price



No	Item	Value	Unit
1	Nominal force	1000	KN
2	Worktable length	2500	mm
3	Distance between holes	2020	mm
4	Depth of throat	320	mm
5	Ram travel	120/150	mm
6	Max opening height	320/350	mm
7	Main power	7.5/11	KW
8	Throat depth	320	mm
9	Weight	6000	kg
10	Dimension	2500*1600*2400	mm

Main purchased components manufacturers



No	Synchronous control proportional valve	Bosch Rexroth
1	Proportional pressure control valve	Bosch Rexroth
2	Oil pump	Bosch Rexroth
3	Seal ring	Japan VALQUA
4	Tubing connector	EMB
5	Motor	Siemens
6	Electrical	Schneider
7	Ball screw	Taiwan HIWIN
8	Linear guide	Taiwan HIWIN
9	grating ruler	Heidenhain
10	Servo motor	ESTUN
11	CNC system	DA52S CNC system

Main Features


1. welded steel structure, by normalizing and high-frequency vibration to eliminate stress, to ensure the overall accuracy of machine tools, has excellent rigidity, anti-distortion, and anti-tilt capability.

2. The two sides master cylinders belong to the electro-hydraulic CNC bending machine CNC axis where Y1, Y2 axes, synchronized compatible with hydraulic servo valve imported from Germany and the German HEIDENHAIN grating closed loop control, accurate feedback, sliders run accurate, repeat slider accuracy and parallel precision can reach +/- 0.01mm.

3. Automatic hydraulic convex compensation system for worktable(V-axis), to address the slider deformation impact of the work piece during the bending. Numbers of compensation automatically adjusted by CNC system, convenient and accurate. ( mechanical compensation table structure for optional)

4. Back gauge(front and rear location) is the X-axis in CNC bending machine, driven by servo motor, CNC system, transmission through precision ball screw, linear guide, synchronous belt wheel, run fast, positioning data accurately. (Users could expand the R-axis or R1 axes, R2 axis, Z1 axis, Z2 axis, etc.)

5. Front feeding device moves lateral through precision linear guide, easily control the spacing between the arms.
Adjustable height level, which greatly improves the convenience of the work piece bending.

6. With fast clamp pallet bending mold, compatible with deflection compensation mechanism.
Combined type of modular CNC bending mold in order to ensure high precision and high efficiency of bending. Adjusting the position of the lower mold handy in different working conditions.

7. Both ends of the machine are equipped with grating ruler, which are used to measure the exact distance between the slide and the worktable. Machinery frame equipped C type plate, grating installed in the C-plate to eliminate the effect of the column deformation on position of the slider. The slider position feedback data will be transferred to the numerical control system immediately to estimated servo valve control signal S1 ~ S2 and the output, control two hydraulic servo valve output flow, so that two cylinders synchronization.

Activities beam structure for the four-point positioning, good stability, Y1, Y2-axis can be individually programmed, can be planted in partial state, tapered bending ( inclined bending).

Suspend pressure maintaining after bending forming to reduce the resilience of the work piece, the pressure maintaining time can be set.

8. Safety barrier around the machinery, and photoelectric protection device to ensure safety working. (laser protection device for optional).

Packing & Delivery
Plastic film, wooden package, or as requirement.
Delivery Detail:        15 days
