• Model NO.：HHW-2 HHW-3 HHW-4
• HS Code：84622990
• Production Capacity：1000PCS,Month

Basic Info.

Model NO. HHW-2 HHW-3 HHW-4 HS Code 84622990 Production Capacity 1000PCS/Month

Product Description

The hydrauic pipe benders are applicable for bending steel pipes up to 90 degree.
They feature simple operation, long service life and smooth round bends.

Model: HHW-2
Max. Pressure: 16T
Max. Stroke: 250mm
Crimp range: Φ 21.3mm-Φ 60mm
Bending formers(in): 1/2" 3/4" 1" 11/4" 11/2" 2"
Pipe wall thickness: 2.75mm-4.5mm
G. W.: 47kg
Volume(cm): 73*32*20

Model: HHW-3
Max. Pressure: 20T
Max. Stroke: 320mm
Crimp range: Φ 21.3mm-Φ 88.5mm
Bending formers(in): 1/2" 3/4" 1" 11/4" 11/2" 2" 21/2" 3"
Pipe wall thickness: 2.75mm-5mm
G. W.: 98kg
Volume(cm): 93*40*21

Model: HHW-4
Max. Pressure: 23T
Max. Stroke: 370mm
Crimp range: Φ 21.3mm-Φ 108mm
Bending formers(in): 1/2" 3/4" 1" 11/4" 11/2" 2" 21/2" 3" 4"
Pipe wall thickness: 2.75mm-6mm
G. W.: 149kg
Volume(cm): 118*46*23
