• Model NO.：Kls25,38-200-530
• Size：500*600*1100mm
• Weight：150kgs
• Processing Speed：6-8m,Min
• Voltage：240V,50Hz,1pH
• Width of Roofing for Curving：220-530mm
• Thickness of Roofing：0.5-0.8mm
• Min. Curved Convex Radius：1m
• Min. Curved Concave Radius：3m
• Motor Power：0.75kw
• After-Saels Service：Engineers Available to Service Machinery Overseas
• Transport Package：Standared Export Package
• Trademark：XHH
• Origin：Xiamen
• HS Code：84552290
• Production Capacity：22sets,Month

Basic Info.

Model NO. Kls25/38-200-530 Size 500*600*1100mm Weight 150kgs Processing Speed 6-8m/Min Voltage 240V/50Hz/1pH Width of Roofing for Curving 220-530mm Thickness of Roofing 0.5-0.8mm Min. Curved Convex Radius 1m Min. Curved Concave Radius 3m Motor Power 0.75kw After-Saels Service Engineers Available to Service Machinery Overseas Transport Package Standared Export Package Trademark XHH Origin Xiamen HS Code 84552290 Production Capacity 22sets/Month

Product Description

KLS25/38-200-530manul metal sheet roof curving machine with convex curved or concave curved, bending machines and Metal plates bending machine detailed information are as follows:

1. Motor Power: 0.75KW]
2. Thickness: 0.5-0.8mm
3. Voltage: 240V/50HZ/1PH
4. Processing Speed: 6-8m/min
5. Min. Curved Convex Radius: 1m
6. Min. Curved Concave Radius: 3m

Usage: Curving normal galvanized and prepainted galvanized steel, and Aluminum roof to curve with convex or concave shape, only convex or concave curved for one piece roofing;

Feature: Can bend the roof panels to Arc-shaped, Wave-shaped with convex curved and Concave curved, with smooth curved;

1.	Dimension	KLS25/38-200-530
2.	Voltage	380V/50HZ/3PH
3.	Motor Power	0.75KW
4.	Thickness	0.5-0.8mm
5.	Working speed	6-8m/min
6.	Effective Width	220-530mm
7.	Feature	Bending roof panels to Arc-shaped
8.	Usage	Bending standing seam roofing panels
