• Model NO.：HJ-005G
• Shear Temperature：>950 Degree
• Steel Types Be Processed：General Carbon Steel, Low-Alloy Steel
• Cylinder Working Pressure：0.4~0.6MPa
• Shear Cylinder：φ100,φ32×240
• Type：Roller-Bending Machine
• Application：Cutting Metal Steel, Machinery & Hardware
• Type for Cutting Machine：Metal Steel Cutting
• Type for Fold-Bending Machine：Steel
• Type for Pipe and Tube Bending Machine：Multifunction Rolling Pipe Bender
• Transport Package：Seaworthy Packing or as Customer′s Request
• Specification：ISO9001, SGS, BV
• Trademark：Hangji
• Origin：Shaanxi, China
• HS Code：8455213000
• Production Capacity：Depending

Basic Info.

Model NO. HJ-005G Shear Temperature >950 Degree Steel Types Be Processed General Carbon Steel, Low-Alloy Steel Cylinder Working Pressure 0.4~0.6MPa Shear Cylinder φ100/φ32×240 Type Roller-Bending Machine Application Cutting Metal Steel, Machinery & Hardware Type for Cutting Machine Metal Steel Cutting Type for Fold-Bending Machine Steel Type for Pipe and Tube Bending Machine Multifunction Rolling Pipe Bender Transport Package Seaworthy Packing or as Customer′s Request Specification ISO9001, SGS, BV Trademark Hangji Origin Shaanxi, China HS Code 8455213000 Production Capacity Depending

Product Description

Gripping shear
The function of the gripping shear
The gripping shear is located in the entrance of the pre-finishing mill and finishing mill, it is used to protect the pre-finishing mill and finishing mill by cutting off the rolled piece and stop further feeding into the mill once there is an operation failure.
Main technical performance

Steel types be processedGeneral Carbon Steel, Low-alloy steel
Shear temperature>950º C
Shear cylinderφ 100/φ 32× 240
Cylinder working pressure 0.4~0.6MPa
Equipment composition and structural characteristics
The gripping shear is composed of support base, main machine of cutting and cylinder, cutting machine is two spindle stuck shear that controlled by pneumatic, one is on top of rolling parts and the other is under the rolling parts, when accident occurs, cylinder moved through the closed sword by promote upper and lower connecting rod, these two swords connected with the moving rolling part and cut down it.
The support base of gripping shear is weld structure.
Lubrication and air compression:
The frame axis of gripping shear adapt oil bearing, the others used manual glycerol lubrication to offer the oil regularly.
The compressed air used in cylinder of the gripping shear is supplied by workshop, the pressure is 0.4~0.6Mpa.

Steel types be processed	General Carbon Steel, Low-alloy steel
cylinder working pressure	0.4~0.6MPa
Shear temperature	Shear temperature
