• Model NO.：WA67Y
• Type for Fold-bending Machine：Hydraulic Fold-bend Machine
• Transport Package：Applicable for Shipping
• Specification：100T,2500D,DK
• Trademark：SLJS
• Origin：China(Mainland)
• Production Capacity：300 Units,Year

Basic Info.

Model NO. WA67Y Type for Fold-bending Machine Hydraulic Fold-bend Machine Transport Package Applicable for Shipping Specification 100T/2500D/DK Trademark SLJS Origin China(Mainland) Production Capacity 300 Units/Year

Product Description

1. Product features:
  ,High precision, high efficiency CNC Torsion Bar Synchro Press Brakes
  Holistic welding structure
  Stabilizes left and right balance with help of the mechanical Torsion Bar
  Double crowning mechanism
 ,,Back gauge is drove by servo motor and performance
 2+1- Y(),X(),V()
Standard configuration with 2+1 axes,Y( upward-downward of cylinder),X( forward-backward of backgague),V( hydraulic crowning)
 2. Standard Configuration

CYBELEC DNC60S Swiss CYBELEC DNC60S system

2+1  CNC controls 2+1 axes(Y,X,V)

Lower hydraulic crowning controlled by CNC system

ESTUN  High-performance servo motor and driver of ESTUN

Original European and American two-layer seals for main cylinders

SCHNEIDER key electrics

Standard Clamping and tool

Standard front support arms



3. CNC System Optional
CYBELEC DNC60S,DELEM DA41 DA51,SA810P
Swiss CYBELEC DNC60S, Holand DELEM DA41, DA51,SA810P



No.	Description	Unit	Parameter
1	Nominal pressure	KN	1000
2	Bending length	mm	2500
3	Distance between uprights	mm	2000
4	Cylinder stroke	mm	160
5	Max. opening height	mm	435
6	Throat depth	mm	350
7	Approach speed	mm/s	90
8	Working speed	mm/s	9
9	Return speed	mm/s	100
10	Motor	KW	7.5
11	Dimension	mm	2700*1600*1575
12	Weight	kg	6700
