W11-10x12000mm 3R Plate Mechanical Plate Rolling Machine
Shanghai Lejia CNC Machine Co., Ltd.- Automation：Automatic
- Type：Roller-Bending Machine
- Type for Cutting Machine：Plate Rolling Machine
- Type for Fold-bending Machine：Plate Rolling Machine
- Transport Package：Applicable for Shipping
- Specification：10x12000mm
Base Info
- Model NO.：W11
- Trademark：SLJS
- Origin：China
- HS Code：8462299000
- Production Capacity：500PCS,Year
Description
ModelMax.rolling
thickness Max.pre-rolling
thickness PlateWidth Diameter of
upper roller Main
motor power (mm) (mm) (mm) (mm) (kw) W11STNC-12x2000 12 10 2000 240 5.5 W11STNC-16x2000 16 12 2000 260 7.5 W11STNC-16x2500 16 12 2500 300 15 W11STNC-18x3000 18 14 3000 350 15 W11STNC-20x3000 20 16 3000 375 22 W11STNC-25x2500 25 20 2500 380 22 W11STNC-30x2500 30 25 2500 410 30 W11STNC-30x3000 30 25 3000 450 30 W11STNC-32x3000 32 28 3000 480 37 W11STNC-35x2500 35 30 2500 460 37 W11STNC-35x3000 35 30 3000 510 37 W11STNC-40x2500 40 35 2500 500 45 W11STNC-40x3000 40 35 3000 540 55
W11STNC-40x4000 40 32 4000 630 55 W11STNC-45x3000 45 40 3000 560 55 W11STNC-45x4000 45 40 4000 610 75 W11STNC-50x4000 50 45 4000 680 75 W11STNC-55x3000 55 45 3000 600 75 W11STNC-55x4000 55 50 4000 730 90 W11STNC-60x3000 60 50 3000 650 75 W11STNC-60x4000 60 55 4000 750 90 W11STNC-65x4000 65 60 4000 780 90 W11STNC-70x3000 70 60 3000 680 75 W11STNC-70x4000 70 65 4000 810 90 W11STNC-75x3000 75 65 3000 720 90 W11STNC-80x3000 80 70 3000 770 90 W11STNC-80x4000 80 75 4000 860 90 W11STNC-90x3000 90 80 3000 780 90 W11STNC-100x3000 100 90 3000 840 90
W11STNC-100x4000 100 85 4000 940 110 W11STNC-110x4000 110 95 4000 960 110 W11STNC-120x3000 120 100 3000 960 90 W11STNC-130x3000 130 110 3000 980 110 W11STNC-150x3000 150 120 3000 990 2x75 W11STNC-160x3000 160 130 4000 1260 2x90
3. Auto compensation for circumferential velocity: Auto distribution of power and AGC auto compensation for work velocity can be achieved by velocity detector on work rolls, pressure sensor on each motor, unique hydraulic system and electric control system.
4. Remote diagnosis: Each sensor is connected with PLC, PLC and camera are connected with computer by industrial control cable, remote diagnosis and control to bending machine can be accomplished by remote control computer via VPN router and INTERNET.
