CNC Wirecut EDM Wire Cut Machine Medium Speed DK7725H
Tengzhou Hoton Machinery Co., Ltd.- After-sales Service:Online
- Warranty:1 year
- Condition:New
- Automation:Automatic
- Worktable size (mm):340x560
- Worktable Travel (mm):250X320
Base Info
- Model NO.:DK7725H
- Max.cut thickness (mm):240
- Taper (optinal):6°,80mm
- Max. Load weight (kg):200
- weight (kg):1400
- Dimensions (mm):1500X1100X2140
- Power supply (kw):2
- Transport Package:Plywood Case
- Trademark:HOTONMC
- Origin:China
- Production Capacity:5000
Description
Product Discription:
1.Appliance of multi-cutting technology of low speed wire cutting and intelligent parameter processing.
2.Appliance of high-frequency electrical power supply with high efficiency and stability . the most processing efficiency ≥150mm2 / min ;
3.Machining quality similar to Low Speed Wire Cutting , the best surface roughness Ra1.5μm.
4.Different control System for choice : HL , HF , AutoCut , etc.Type Worktable size
(mm) Worktable Travel
(mm) Max.cut thickness
(mm) Taper
(optinal) Max. Load
weight
(kg) Net weight
(kg) Dimensions
(mm) Power supply
(kw) DK7725H 340x560 250X320 240 6°/80mm 200 1400 1500X1100X2140 2KW DK7732H 380x650 320X400 240 6°/80mm 300 1600 1600X1250X2180 2KW DK7740H 410x710 400X500 240 6-60°/80mm 450 1680 1850X1500X2100 2KW DK7750H 596X880 500X630 340 6-60°/80mm 800 2100 2100X1800X2400 2KW DK7763H 720X1260 630X800 420/320 6-60°/80mm 1000 3500 2360X2250X2550 2KW DK7780H 880X1440 800X1000 500/400 6-60°/80mm 1500 4700 2700X2300X2600 2KW
1.Appliance of multi-cutting technology of low speed wire cutting and intelligent parameter processing.
2.Appliance of high-frequency electrical power supply with high efficiency and stability . the most processing efficiency ≥150mm2 / min ;
3.Machining quality similar to Low Speed Wire Cutting , the best surface roughness Ra1.5μm.
4.Different control System for choice : HL , HF , AutoCut , etc.
(mm)
(mm)
(mm)
(optinal)
weight
(kg)
(kg)
(mm)
(kw)
