Onejet50-G40*20 Waterjet Cutting Machine for Metal Sheet Cold Cutting

ONEJET WATERJET CO.,LTD
  • After-sales Service：7X24h
  • Warranty：18 Months
  • Certification：CE
  • Condition：New
  • Control：Automatic
  • Application：Metal, Rubber, Ceramic, Glass, Stone, Plastic, Leather, Fabric, Slabs

Base Info

  • Model NO.：ONEJET50-G40*20
  • Power Source：Electric
  • Style：Gantry
  • Type：Three-Axis
  • Bearing Pressure：60000psi
  • Working Pressure：0-380MPa
  • Cutting Size：4000X2000mm
  • Cutting Accuracy：0.1mm
  • Cutting Thickness：0-150mm
  • Servos：Wise,Yaskawa
  • Main Motor：Siemens
  • Soft Starter：Siemens
  • Maxi Flowrate：3.5L,Min
  • Axis：3,5
  • Head：1,2,4 Heads
  • Covers：Stainless Steel
  • Proof：Water&Dust
  • Weight：4500kgs
  • Container Need：20 Feet
  • Transport Package：Delivery by Sea or Train in Container
  • Specification：4400X2200X2000MM
  • Trademark：One Jet
  • Origin：Foshan, China
  • HS Code：8456500000
  • Production Capacity：5 Sets Per Month

Description

TECHNICAL SPECIFICATIONSMachine DemensionWork Envelope180mm or customizedDry running speed: X-Y  10000mm/min, Z  5000mm/min;     Repeatability: ±0.0254mm;     Cutting accuracy:±0.10mmBENEFITS & FEATURES1, Machines are highly designed in South America and produced in China with strict production control, 2, All top brands parts in machine, This ensures machine stable working and long life.3, High accurate & High skilled assembly engineers.4, Easy operation: NCstudio/ESA/ECS control for choose, programm easy and opertaion simple. cutting parameters date inside control5, SERVOS: ALL servos in XYZ, M2, Absolutely value servos6,Auto Lubrication system for all motion parts7,Pressure can be adjustable in control system from 0-380mpa any time and any points. Save energy in cutting different materials8,Integrated control with cutting table: save space, reduce wires problem compared with independently controler; fantastic looking; better operation;easy for trouble  shoot.9,Accuracte abrasive feeding hopper with step motor controling,this ensures feeding continuous and accurately. Water & dust seals, backwater protection10,All stainless steel covers for pump, cutting table, all stainless steel for controler,better protection11, All water & dust proof design for the machineOnejet50-G40*20 Waterjet Cutting Machine for Metal Sheet Cold Cutting
