CCD Camera Precise and Fast High Pressure Cardboard/Kraft Paper/Acrylic Sheet Cutting Plotter Flatbed Digital Die Cutter for Package Proofing

Hefei Saga Computer Numerical Control Co., Ltd.
  • After-sales Service：Lifetime Service
  • Waterproof Rating：IPX-0
  • Warranty：1-year
  • Certification：CE, RoHS
  • Condition：New
  • Control：Automatic

Base Info

  • Model NO.：FC 9901220
  • Application：Paper
  • Power Source：Electric
  • Layout：Horizontal
  • Max Cutting Speed：700mm,S
  • Max Cutting Force：1500g
  • Blade Types：Blade, Creasing Tool and Pen
  • Positioning Sensor Type：CCD Digital Camera
  • Media Hold Method：Vacuum Suction
  • Cutting Control System：Digital Servo System
  • Effective Cutting Area：1000mm*1290mm
  • Actual Dimensions：1886.5mm*1528mm*1000mm
  • Package Dimensions：1954mm×1656mm×620mm
  • Gw：275
  • Working Voltage：110-240V 50,60Hz
  • Power：1.45kw-1.65kw
  • Interface：USB,Network Cable
  • Transport Package：Export Wooden Package
  • Specification：1886.5mm*1528mm*1000mm
  • Trademark：saga
  • Origin：Hefei China
  • HS Code：84411000
  • Production Capacity：10000PCS

Description

Machine performanceMedia hold methodVacuum suctionPositioning sensor typeDigital camera(CCD)Maximum cutting size1000mm×1290mmMaximum ARMS Contour Cutting Size990mm×1220mmScanning speed5-10sSoftware and compatibilityPower and working envionment requirementsVoltage and current100VAC-120VAC.50/60Hz,Maximum current 6.8A
200VAC-240VAC,50/60Hz,Maximum current 3.4APower350WVoltage and current(Vacuum Pump)110VAC, 50Hz, Rated current 12.4A, 60Hz, Rated current 17.2A
220VAC, 50Hz, Rated current  6.2A,60Hz, Rated current 8.6APower(Vacuum Pump)50Hz, 1.1KW;60Hz,1.3KWStandIncludedOperation environmentTemperature+5ºC to +35ºC(Fahrenheit 41-95),Humility 30%-75%(Non-condensing)Dimensions and weightsActual dimensions1886.5mm×1528mm×1000mmPackage dimensions1954mm×1656mm×620mmGW275kg
