Portable Mini CNC Plasma Flame Stainless Steel Carbon Steel Metal Cutting Machine

Wuhan Lan-Sun Technology Co., Ltd.
  • After-sales Service：Perfect and Durable Service: Online Service
  • Warranty：1 Years
  • Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Control：Automatic
  • Application：Metal

Base Info

  • Model NO.：ZLQ-14B
  • Connected Shaft Number：2-Shaft
  • Style：Portable
  • Type：CNC
  • Control System：Hypertherm Start-2000 Wuhan LAN Sun-IV Lansun V
  • Working Mode：Untouched Arc Striking
  • Interface：USB
  • Power Supply：Hypertherm Powermax1650 Kliby Fine Focus450 China
  • Plasma Generator Power：65A 85A 120A 200A for Much Thickness Cutting
  • Transport Package：Wood Box
  • Specification：3000*7000
  • Trademark：Lan-Sun
  • Origin：China
  • HS Code：84569010
  • Production Capacity：1000sets,Year

Description

Main Technical Performance Indexes of productsModelZLQ-14BEffective Cutting area (mm)1500x3000           1500x4000              1500x6000Cutting Thickness(mm)Flame:5-60mm,              Plasma:1-25mmCutting Speed (mm/min)50-3800Running speed (m/min)1.20Cutting ModeFlame/plasma/flame and plasmaDrive Motor Numberstepper motor , single-sideCutting Torch NumberCustomize according user's needNC ControllerLANSUN or Shanghai Or BeijingProgramming softwareStartcam or FastcamOperation languageEnglish or Chinese or RussianVoltage220V/380VPlasma generator63A,100A ,120A , 200A ect . China , USA brandPower voltage3×380V±10% or up by user's local conditionSurroundingsVentilation, no big shakeHumidity<90%, no condensationWorking temperature- 10°C -45°C CertificationPortable Mini CNC Plasma Flame Stainless Steel Carbon Steel Metal Cutting MachinePortable Mini CNC Plasma Flame Stainless Steel Carbon Steel Metal Cutting MachinePortable Mini CNC Plasma Flame Stainless Steel Carbon Steel Metal Cutting Machine
The company has a strict quality management system, and its products have passed the ISO9001 quality management system certification and the European Union "CE" certification
