Small Size Water Jet Cutting Machine for Jade Cutting

ONEJET WATERJET CO.,LTD
  • After-sales Service：7X24h
  • Warranty：1 Year
  • Certification：CE
  • Condition：New
  • Control：CNC
  • Application：Metal, Rubber, Ceramic, Glass, Stone, Plastic, Leather, Fabric, Jade

Base Info

  • Model NO.：ONEJET50-G15*15
  • Power Source：Electric
  • Style：Gantry
  • Type：Three-Axis
  • Maxi Bearing Pressure：420MPa,60000psi
  • Working Range：1500X1500mm
  • Main Motor：50HP,37kw
  • PLC：Omron
  • Servos：Yaskawa,Wise
  • Soft Starter：Siemens,Top Chinese Brand
  • Pressure Adjustable：0-380MPa
  • Guid Linear and Ball Screw：Hiwin&Tbi
  • Cutting Accuracy：0.1mm
  • Power：380,415,220
  • Transport Package：Pep Inside and Thin Film Outside, Fixed in Contain
  • Specification：1500X1500mm
  • Trademark：ONEJET
  • Origin：Guangdong, China
  • HS Code：8456500000
  • Production Capacity：5 Sets Per Month

Description

TECHNICAL SPECIFICATIONSMachine DemensionWork Envelope180mm or customizedModelG15*15G25*15G30*15G30*20G40*20G20*60G25*60Working RangeX1500mm2500mm3000mm3000mm4000mm2000mm2500mmY1500mm1500mm1500mm2000mm2000mm6000mm6000mmCutting Acuracy±0.10mmRepositioning Acuracy±0.03mmLubricationAuto lubrication systemDriver motorsPanasonic/Yaskawa/WISEMaxi travel speedX,Y 9600mm/min; Z 5000mm/minCutting headThree axis headFive Axis AC  headNOSyetemNcstudio based on Windows 7ProgrammNcEditor, AutoCADCapacity filesDXF,G codes,nce,nc etcCovers and protectionsAll stainless steel covers with water & dust proof designControl hardwareIntel Core dual;RAM 4GB; HD SSD 250G; 19inch screen;wireless keyboard and mouse; two USBOptionalsESA SYSTEM/ECS SYSTEM/LANTEK Small Size Water Jet Cutting Machine for Jade CuttingSmall Size Water Jet Cutting Machine for Jade CuttingSmall Size Water Jet Cutting Machine for Jade CuttingSmall Size Water Jet Cutting Machine for Jade CuttingSmall Size Water Jet Cutting Machine for Jade Cutting
