High-speed DK Series Electric Discharge Machine DK350 CNC Wire EDM
Tengzhou Hoton Machinery Co., Ltd.- After-sales Service：Online
- Warranty：1 year
- Condition：New
- Automation：Automatic
- Worktable size (mm)：720X500
- Worktable Travel (mm)：450X350
Base Info
- Model NO.：DK350
- Max.cut thickness (mm)：500
- Max. Load weight (kg)：350
- weight (kg)：1350
- Dimensions (mm)：1500X1200X1520
- Power supply (kw)：2
- Accuracy (GB/T)：0.001
- Molybdenum wire diameter (mm)：0.12~0.2
- Taper (optinal)：6degree ,80mm
- Transport Package：Plywood Case
- Trademark：HOTONMC
- Origin：China
- Production Capacity：5000
Description
Product Discription:
1.Adopt cutomized jellery membrane and aluminum outflow plate.
2.The waterproof cover of the rear guide pulley is cleaner.
3.Adopt waterproof blind-through guide wheel for easy operation.
4.Nano material is adopted for the water shield , which is crack-proof explosion-proof , soild and durable.
5.It is more convenient to slide the water retaining cover.
Universal Optional Accessories :
1 . The water-retaining plate is optional.
Aluminum Cutting Optional Accessories :
1 . Electronic ruler matching
2 . the linear guideway is adopted for wire traveling
3 . the helical gear is adopted for wire traveling gear.
4 . the skewed tooth is adopted for the stepping motor
1.Adopt cutomized jellery membrane and aluminum outflow plate.
2.The waterproof cover of the rear guide pulley is cleaner.
3.Adopt waterproof blind-through guide wheel for easy operation.
4.Nano material is adopted for the water shield , which is crack-proof explosion-proof , soild and durable.
5.It is more convenient to slide the water retaining cover.
Universal Optional Accessories :
1 . The water-retaining plate is optional.
Aluminum Cutting Optional Accessories :
1 . Electronic ruler matching
2 . the linear guideway is adopted for wire traveling
3 . the helical gear is adopted for wire traveling gear.
4 . the skewed tooth is adopted for the stepping motor
| Type | Worktable size (mm) | Worktable Travel (mm) | Max.cut thickness (mm) | Max. Load weight (kg) | Taper (optinal) | Molybdenum wire diameter (mm) | Accuracy (GB/T) | Dimensions (mm) | Weight (kg) |
| DK350 | 720X500 | 450X350 | 500 | 350 | 6°/80mm | 0.12~0.2 | 0.001 | 1500X1200X1520 | 1350 |
| DK450 | 820X560 | 550X450 | 500 | 400 | 6°/80mm | 0.12~0.2 | 0.001 | 1670X1540X1600 | 1600 |
| DK450B | 920X560 | 630X450 | 500 | 400 | 6°/80mm | 0.12~0.2 | 0.001 | 1670X1600X1600 | 1800 |
| DK550 | 1160X740 | 800X550 | 600 | 500 | 6°/80mm | 0.12~0.2 | 0.001 | 1800X1600X1850 | 2000 |
| DK630 | 1360X844 | 1000X630 | 800 | 600 | 6°/80mm | 0.12~0.2 | 0.001 | 2300X1900X2100 | 3000 |
| DK800 | 2160X1044 | 1200x800 | 800 | 800 | 6°/80mm | 0.12~0.2 | 0.001 | 2600x2050X2300 | 4000 |
