• Model NO.：PEL-200
• Type：Roller-Bending Machine
• Bending Material：Ss, Alumnium
• Bending Thickness：Max 1.5mm
• Bending Width：160mm
• Function：Notching, Bending and Cutting
• Feed Speed：5~20 M, Min
• Application：Aluminum,Stainless Steel,Carbon Steel ,Galvanized
• Aluminum Bending Thickness：0.5-1.5 mm
• Stainless Steel Bending Thickness：0.5 -1.2mm
• Galvanize Plate Bending Thickness：0.5 -1.0 mm
• Carbon Steel Bending Thickness：0.5-1.0mm
• Transport Package：Wood Craftcase
• Specification：CE, ISO2001: 9000, TUV, SGS
• Trademark：Perfect Laser
• Origin：Hubei Wuhan
• Production Capacity：1000 Units,Month

Basic Info.

Model NO. PEL-200 Type Roller-Bending Machine Bending Material Ss, Alumnium Bending Thickness Max 1.5mm Bending Width 160mm Function Notching, Bending and Cutting Feed Speed 5~20 M/ Min Application Aluminum/Stainless Steel/Carbon Steel /Galvanized Aluminum Bending Thickness 0.5-1.5 mm Stainless Steel Bending Thickness 0.5 -1.2mm Galvanize Plate Bending Thickness 0.5 -1.0 mm Carbon Steel Bending Thickness 0.5-1.0mm Transport Package Wood Craftcase Specification CE, ISO2001: 9000, TUV, SGS Trademark Perfect Laser Origin Hubei Wuhan Production Capacity 1000 Units/Month

Product Description

Metal Stainless Steel Aluminum Automatic CNC Channel Letter Bending Machine
 Product Advantages for led channel letter bending machine :
 1) Friendly man-machine interface, simple configuration, touch-screen operation. Simply enter the
processing of text, graphic design files, and then the machine can process them on materials automatically.
 2) A unique three-dimensional process simulation technology, two-dimensional design file to be able to display three-dimensional effects, supplemented by translation, rotation, zoom and other functions, enables
full observation and monitoring of whole working process.
 3) The original double-bent knife parallel bending technology to save time and greatly improve the
 processing efficiency, the maximum bending angle reached 130 °.
 4) High precision machining, feeding precision can reach 0.01mm, bending accuracy up to 0.4 °.
 5) With precision automatic calibration function, based on the way of the processing material, self-adjusting process parameters, so that it can match with a variety of engraving machines and cutting machine, meet a variety of complex embedded process accuracy as much as possible.
 6) Wide range of applications: CNC Bending machine can process 0-1.5mm strip of aluminum, galvanizedsteel, iron and other metal sheet.
 7) It can work in 0.05 precision, and work together with laser engraving machine, plasma cutting machine torealize the advertisement processing.
