High Technology Full Automatic Pipe Bender Tube Bender GM-38ncba

Zhangjiagang King-Macc Machinery Manufacturing Co., Ltd.
  • Waterproof Rating：IPX-8
  • Warranty：2-year
  • Condition：New
  • Certification：ISO 9001:2000, CE, UL
  • Automation：Semi-Automatic
  • Suitable for：Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel

Base Info

  • Model NO.：GM-38NCBA
  • Type：Pipe and Tube Bending Machine
  • Transport Package：Iron Frame
  • Specification：2800X1500X1800mm
  • Trademark：GMACC
  • Origin：China
  • HS Code：8462219000
  • Production Capacity：5000PCS,Year

Description

Basic Info.

Model NO. GM-38NCBA Type Pipe and Tube Bending Machine Transport Package Iron Frame Specification 2800X1500X1800mm Trademark GMACC Origin China HS Code 8462219000 Production Capacity 5000PCS/Year

Product Description

GM-SB-38NCBA Automatic three Dimensional
Pipe Bending Machine

Machine Characteristics
GM-SB-38NCBA series single-head bending machine, importing advanced design technology from Italy, is a kind of automatic three-dimensional pipe bending machine, integrated with machine, hydraulic, and electricity. Various data and orders can be input and stored in advanced imported touch screen, which can automatically rotate the angle in three dimension continuously, besides, manual material feeding meets the requirement for processing precision of complicated work pieces all make NC series a professional and high speed European pipe bending equipment.
Main Technical Parameter
NameUnit  Parameter
Max. Bending Capacity    mm¢38*2
Bending Radius Rangemm20-200
Max. Bending Angle°190°
Though Effective Distancemm2200
Bending speed°/sec60
Turning speed°/sec200
Bending precision°±0.10
Turning precision°±0.10
Rotating Servomotor PowerKW0.4
System Motor PowerKW4
Oil Pump Delivery VolumeL14
Max. PressureMpa16
L*W*H (Packaging Dimension)mm3500*700*1300
WeightT2.0

 Configuration of Hydraulic and Electronic Control System
NameManufacturer
Hydraulic MotorGermany Siemens( Imported)or Wuxi Taihu
Hydraulic PumpTaiwan Hydromax(Imported)
Hydraulic ValveJapan Yuken(Imported)
Oil way BoardSuzhou Boguan
CylinderShanghai Qifan
Oil tubeSuzhou Kejia
Touch screenTaiwan Weinview(Imported)
PLCJapan Mitsubishi(Imported)
Servo MotorJapan Mitsubishi(Imported)
Angle controllerJapan Nemicon(Imported)
Switch powerWenzhou Changxing
ContactorGerman SCHNEIDER(Imported)
Other Electric PartsGerman SCHNEIDER,Omron, Taiwan SHILIN(Imported)
